Wireless Modules

This specification is for the LBWA1UZ1GC (imp005) module that provides connectivity to the internet via WiFi or Ethernet.

Integrated cellular end device, ultra-small, highly integrated, certified end device with antenna connection for ease of integration.

The DM2200-916VM is a 916.5 MHz transceiver module designed for wireless sensor network applications, combining low-current ASH radio technology with low-power microprocessor technology for long battery life.

433.92 MHz transceiver module designed for wireless sensor network applications.

916.5 MHz router module in the DM1810 family of RF transceivers for wireless mesh connectivity.

The DM1810-916MN is the 916.50 MHz field node module in the DM1810 family of RF transceivers, designed for adding wireless mesh network connectivity to monitoring and control systems.

The DM1810-916MB is the 916.50 MHz base station module in the DM1810 family of RF transceivers, designed for adding wireless mesh network connectivity to monitoring and control systems.

The DM1810-434MR is the 433.92 MHz router module in the DM1810 family of RF transceivers, designed for adding wireless mesh connectivity to monitoring and control systems.

RF Transceiver Modules and Modems RoHS

2.4GHz 802.15.4 -40°C~85°C 2.4V~3.4V I2C, JTAG, SPI, UART Bulk Integrated, Chip 250 kbps 20dBm Zigbee® -103dBm Module

2.4GHz 802.15.4 -40°C~85°C 2.4V~3.4V I2C, JTAG, SPI, UART Bulk Integrated, Chip 250 kbps 20dBm Zigbee® -103dBm Module

2.4GHz 802.15.4 -40°C~85°C 3.3V~5.5V SPI, UART Bulk 250kbps 17dBm Zigbee® Module

2.4GHz 802.15.4 -40°C~85°C 3.3V~5.5V SPI, UART 250kbps 17dBm Zigbee® -95dBm Module

2.4GHz 802.15.4 -40°C~85°C 2.7V~5.5V SPI, UART 250kbps 0dBm Zigbee® -94dBm Module

2.4GHz 802.15.4 -40°C~85°C 5.5V Tray Antenna Not Included, U.FL 250kbps 8dBm -92.5dBm Module

2.4GHz Bluetooth -40°C~85°C 3.3V SPI, UART, USB Bulk Antenna Not Included, U.FL 2Mbps Bluetooth v2.0 + EDR -84dBm Module

2.4GHz Bluetooth -40°C~85°C 3.3V Bulk 2Mbps Bluetooth v2.0 + EDR -84dBm Module

2.4GHz Bluetooth -40°C~85°C 3.3V Bulk Integrated, Chip 2Mbps 3dBm Bluetooth v2.0 + EDR -84dBm Module

2.4GHz Bluetooth -40°C~85°C 3.1V~3.6V SPI, UART, USB Bulk Antenna Not Included, U.FL 2Mbps 18dBm Bluetooth v2.0 + EDR, Class 1 -82dBm Module

2.4GHz Bluetooth -40°C~85°C 3.1V~3.6V SPI, UART, USB Bulk Antenna Not Included, U.FL 2Mbps 18dBm Bluetooth v2.0 + EDR, Class 1 -82dBm Module

2.4GHz Bluetooth -40°C~85°C 3.1V~3.6V SPI, UART, USB Bulk Integrated, Chip 2Mbps 18dBm Bluetooth v2.0 + EDR, Class 1 -82dBm Module

2.4GHz Bluetooth -40°C~85°C 3.1V~3.6V SPI, UART, USB Bulk Integrated, Chip 2Mbps 18dBm Bluetooth v2.0 + EDR, Class 1 -82dBm Module

2.4GHz WiFi -40°C~85°C 3V~3.6V SPI, UART Bulk Integrated, Chip 11Mbps 10dBm 802.11a/b/g/n -92dBm Module

2.4GHz WiFi -40°C~85°C 3V~3.6V SPI, UART Tray Integrated, Chip 11Mbps 10dBm 802.11b/g -92dBm Module

2.4GHz WiFi -40°C~85°C 3V~3.6V SPI, UART Bulk Antenna Not Included, U.FL 11Mbps 10dBm 802.11a/b/g/n -92dBm Module

2.4GHz WiFi -40°C~85°C 3V~3.6V SPI, UART Tray Antenna Not Included, U.FL 11Mbps 10dBm 802.11b/g -92dBm Module

2.4GHz WiFi -40°C~85°C 3V~3.6V SPI, UART Bulk Integrated, Chip 11Mbps 10dBm 802.11b/g -92dBm Module

2.4GHz WiFi -40°C~85°C 3V~3.6V SPI, UART Bulk Integrated, Chip 11Mbps 10dBm 802.11b/g -92dBm Module

2.4GHz WiFi -40°C~85°C 3V~3.6V SPI, UART Bulk Antenna Not Included, U.FL 11Mbps 10dBm 802.11b/g -92dBm Module

2.4GHz WiFi -40°C~85°C 3V~3.6V SPI, UART Tray Antenna Not Included, U.FL 11Mbps 10dBm 802.11b/g -92dBm Module

2.4GHz Bluetooth, WiFi -40°C~85°C 3V~4.2V UART Tape & Reel (TR) 3Mbps 8dBm 802.11a/b/g/n, Bluetooth v4.1 -90dBm Module

2.4GHz Bluetooth, WiFi -40°C~85°C 3V~4.2V UART Tape & Reel (TR) 65Mbps 8dBm 802.11b/g/n, Bluetooth v4.0 Dual Mode -90dBm Module

2.4GHz WiFi -40°C~85°C SDIO, UART Tape & Reel (TR) 65Mbps 16dBm 802.11b/g/n Module

2.4GHz General ISM > 1GHZ -40°C~70°C 3.3V~10V UART Bulk Antenna Not Included 460.8kbps 18dBm -90dBm Module

2.4GHz General ISM > 1GHZ -40°C~70°C 3.3V~10V UART Bulk Antenna Not Included, MMCX 460.8kbps 24dBm -92dBm Module

2.4GHz General ISM > 1GHZ -40°C~85°C 3.3V~10V UART Bulk Antenna Not Included, MMCX 460.8kbps 24dBm -92dBm Module

2.4GHz General ISM > 1GHZ -40°C~70°C 3.3V~10V UART Bulk Antenna Not Included 460.8kbps 14dBm -92dBm Module

2.4GHz General ISM > 1GHZ -30°C~70°C 3.3V~10V UART Bulk Antenna Not Included 921.6kbps 18dBm Module

2.4GHz General ISM > 1GHZ -40°C~70°C 3.3V~10V UART Bulk Antenna Not Included, MMCX 460.8kbps 18dBm -93dBm Module

2.4GHz~2.483GHz General ISM > 1GHZ -40°C~70°C 3.3V~10V UART Antenna Not Included, MMCX 460.8kbps 18dBm -93dBm Module
