PD70-01B/TR7 [EVERLIGHT]

Name: PD70-01B/TR7
Brand: EVERLIGHT
SKU: PD70-01B/TR7
Availability: InStock

Part No:

PD70-01B/TR7

Category:

Optical Detectors & Sensors

Manufacturer:

EVERLIGHT

Description:

Surface Mount -25°C~85°C Tape & Reel (TR) Wavelength: 940nm 2-SMD, Gull Wing 5nA

RoHS Status:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Factory Lead Time

15 Weeks

Mount

Surface Mount

Mounting Type

Surface Mount

Package / Case

2-SMD, Gull Wing

Number of Pins

2

Shape

RECTANGULAR

Semiconductor Material

Silicon

Operating Temperature

-25°C~85°C

Packaging

Tape & Reel (TR)

Published

2012

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

3 (168 Hours)

Additional Feature

DAYLIGHT FILTER

HTS Code

8541.40.60.50

Max Power Dissipation

150mW

Number of Functions

1

Configuration

SINGLE

Diode Type

Power Dissipation

150mW

Size

4.4mm

Rise Time

50ns

Fall Time (Typ)

50 ns

Max Reverse Voltage (DC)

32V

Reverse Breakdown Voltage

32V

Wavelength

940nm

Reverse Voltage (DC)

32V

Dark Current

5nA

Spectral Range

730nm ~ 1100nm

Infrared Range

YES

Light Current-Nom

0.035mA

RoHS Status

RoHS Compliant

Products Detail

PD70-01B/TR7 Overview

Tape & Reel (TR) is used to protect the photodiodes from damage. A safety package containing the photodiodes is provided for their protection. When the photodiodes are reverse-biased, the voltage should never exceed 32V. A photodiode has a pin number of 2. There was the possibility that photodiodes in a circuit would emit 150mW heat. The reverse anode voltage for the photodiodes should be 32V. In general, the maximum heat generated by photodiodes should be 150mW in a circuit. With the reverse voltage of 32V, the photodiodes in the DC circuit can work properly. The current in a photodiode is 5nA even when there is no light input.

PD70-01B/TR7 Features

Moisture Sensitivity Level (MSL): 3 (168 Hours)
Operating Temperature: -25°C~85°C
Packaging: Tape & Reel (TR)
Diode Type: PIN
Mount: Surface Mount
Spectral Range: 730nm ~ 1100nm

PD70-01B/TR7 Applications

There are a lot of Everlight Electronics Co Ltd
PD70-01B/TR7 Photodiodes applications.

Shaft encoders
Electronic Equipment
Industrial Automation
Machine Controls
Light Barriers
Vision Controls
Measurement Levelling
High speed photo detectors
Health Monitoring
Heart Rate Monitoring

Product FAQ

1. Is PD70-01B/TR7 available for RFQ?

Yes. PD70-01B/TR7 by EVERLIGHT is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

2. Why is there no fixed price for PD70-01B/TR7?

Pricing for PD70-01B/TR7 can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

3. What are the key specifications of PD70-01B/TR7?

PD70-01B/TR7 is a EVERLIGHT Optical Detectors & Sensors with Packaging: Tape & Reel (TR) and Moisture Sensitivity Level (MSL): 3 (168 Hours) and Reverse Breakdown Voltage: 32V. Review the product details or submit an RFQ if you need confirmation before purchase.

4. How fast can I get a quote for PD70-01B/TR7?

Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

5. How soon can PD70-01B/TR7 be shipped?

If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

6. Can you suggest alternatives to PD70-01B/TR7?

Yes. If PD70-01B/TR7 is unavailable, obsolete, or does not meet your required lead time, we can help check similar EVERLIGHT Optical Detectors & Sensors parts or compatible alternatives.
