Name: FR20D02
Brand: GeneSiC Semiconductor
SKU: FR20D02

FR20D02 [GeneSiC Semiconductor]

Part No:

FR20D02

Diodes & Rectifiers

Manufacturer:

GeneSiC Semiconductor

Description:

Standard Diode Rectifier Fast Recovery =< 500ns, > 200mA (Io) 1V @ 20A -40°C~125°C 25?A @ 50V 1-Termination Bulk DO-203AB, DO-5, Stud Chassis, Stud Mount

Package:

-

RoHS Status:

Datasheet:

-

Production Status:

In Stock Status:

Specification

Type

Parameter

Lifecycle Status

PRODUCTION (Last Updated: 5 months ago)

Factory Lead Time

10 Weeks

Mount

Cable, Chassis, Stud

Mounting Type

Chassis, Stud Mount

Package / Case

DO-203AB, DO-5, Stud

Diode Element Material

SILICON

Packaging

Bulk

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

Max Operating Temperature

105°C

Min Operating Temperature

-40°C

Pitch

5.08mm

Terminal Position

UPPER

Orientation

Straight

Terminal Form

SOLDER LUG

JESD-30 Code

O-MUPM-D1

Number of Contacts

Number of Elements

Configuration

SINGLE

Speed

Fast Recovery =< 500ns, > 200mA (Io)

Diode Type

Standard

Voltage - Forward (Vf) (Max) @ If

1V @ 20A

Case Connection

CATHODE

Forward Current

20A

Operating Temperature - Junction

-40°C~125°C

Max Surge Current

250A

Max Reverse Voltage (DC)

200V

Average Rectified Current

20A

Number of Phases

Reverse Recovery Time

200 ns

Max Repetitive Reverse Voltage (Vrrm)

200V

Reverse Voltage

200V

Recovery Time

200 ns

Natural Thermal Resistance

0.6 °C/W

RoHS Status

RoHS Compliant

Products Detail

FR20D02 Overview

A reasonable reverse voltage is 200V.The average rectified current for this device is 20A volts.When the forward current reaches 20A, it is allowed.Objects and materials resist heat flow by their thermal resistance, and their natural thermal resistance is 0.6 °C/W.The maximum surge current is 250A.A data chart shows that the peak reverse is 25?A in the datasheets.

FR20D02 Features

an average rectified current of 20A volts
the peak reverse is 25?A

FR20D02 Applications

There are a lot of GeneSiC Semiconductor
FR20D02 applications of single-phase diode rectifier.

DC motor control and drives
Battery chargers
Welders
Power converters
Reverse Polarity Protection
Ultra High-Speed Switching
Freewheeling
Polarity Protection Diode
Recirculating Diode
Switching Diode

Key Features

No key features available

Application scenarios

No application scenarios available
