Name: M80-7700642
Brand: Harwin
SKU: M80-7700642

M80-7700642 [Harwin]

Part No:

M80-7700642

Unspecified Connectors

Manufacturer:

Harwin

Description:

2 Rows Receptacle Solder Beryllium Copper Through Hole Tube Gold Polyamide (PA46), Nylon 4/6 6 Positions Female Socket

Package:

-

RoHS Status:

Datasheet:

Production Status:

In Stock Status:

Specification

Type

Parameter

Contact Material

Beryllium Copper

Mounting Type

Through Hole

Contact Shape

Circular

Insulation Material

Polyamide (PA46), Nylon 4/6

Operating Temperature

-55°C~125°C

Packaging

Tube

Series

Datamate L-Tek

Published

2011

JESD-609 Code

Pbfree Code

yes

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Termination

Solder

ECCN Code

EAR99

Connector Type

Receptacle

Number of Positions

Applications

Automotive, General Purpose, Military

Number of Rows

Voltage - Rated

120V

Additional Feature

POLARISED

Fastening Type

Locking Ramp

Contact Finish - Mating

Gold

MIL Conformance

DIN Conformance

IEC Conformance

Filter Feature

Contact Type

Female Socket

Mixed Contacts

Insulation Height

0.202 5.14mm

Style

Board to Board or Cable

Number of Positions Loaded

All

Reach Compliance Code

not_compliant

Pitch - Mating

0.079 2.00mm

Insulation Color

Black

Number of Conductors

ONE

Reliability

COMMERCIAL

Row Spacing - Mating

0.079 (2.00mm)

Contact Length - Post

0.177 4.50mm

Number Of PCB Rows

Contact Finish - Post

Tin

PCB Contact Pattern

RECTANGULAR

UL Flammability Code

94V-0

Mating Contact Pitch

0.079 inch

Polarization Key

POLARIZED HOUSING

Length - Termination

0.177 inch

Stack Height (Mating)

7.23mm 7.85mm

Material Flammability Rating

UL94 V-0

RoHS Status

RoHS Compliant

Products Detail

M80-7700642 Overview

The product comes in a package of Receptacle.Through Hole is the type of mounting for the device.To package the product, a Tube case is used.The product is a member of the Datamate L-Tek Series.Among other features are POLARISED, to name only a few.The device may be used for the following applications: Automotive, General Purpose, Military.It operates at an operating temperature of -55°C~125°C.

M80-7700642 Features

Datamate L-Tek series

M80-7700642 Applications

There are a lot of Harwin Inc.
M80-7700642 Rectangular Connectors applications.

Embedded systems
Datacom
Communication
Medical technology
Military Technology
Measuring & Control Technology
Instrumentation
Automotive Electronics
Telecommunications
Data Technology

Key Features

No key features available

Application scenarios

No application scenarios available
