FB10S021JA2R6000 [JAE]

Name: FB10S021JA2R6000
Brand: JAE
SKU: FB10S021JA2R6000
Availability: InStock

Part No:

FB10S021JA2R6000

Category:

FFC / FPC

Manufacturer:

JAE

Description:

The FB10 Series is a 0.3mm pitch, low profile, bottom-surface connection type FPC connector that is ideally suited for ever-smaller hand-held devices such as smartphones and tablet PCs.

RoHS Status:

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Voltage Rating

AC, DC 50V per contact

Contact Resistance

80mΩ

Rated Current

DC 0.35A per contact

Operating Temperature

-40°C ~ +85°C

Pitch

0.3mm

Packing

Tape and reel (6000 pcs.)

RoHS Status

RoHS Compliant

Housing Material

Heat-resistant resin (Halogen-free)

Halogen Free

Yes

Actuator Material

Heat-resistant resin (Black, Halogen-free)

Applicable Fpc Thickness

0.2 ± 0.03mm

Contact Plating

Au over Ni (0.1µm min for contact, 0.03µm min for terminal)

Dielectric Withstanding Voltage

AC250 Vr.m.s per minute

Mating Cycles

20 mating cycles

Pb Free

Yes

Products Detail

The FB10 Series is a space-saving FPC connector with 0.3mm pitch, 0.9mm overall height, and 2.5mm depth. It features ZIF structure, bottom-surface connection, guides to prevent FPC misalignment, easy actuator operation, and allows board pattern traces under the connector. The connector is Pb-free, halogen-free compliant, has a Ni barrier to prevent solder wicking, and supports rated current of DC 0.35A per contact. It is designed for applications requiring compact and reliable FPC connections.

Key Features

Space-saving design (0.3mm pitch, 0.9mm height, 2.5mm depth)
Applicable FPC thickness 0.2±0.03mm
ZIF structure
Bottom-surface connection
Guides for FPC sides to prevent misalignment
Easy actuator operation
Open actuator lightly locked
Board pattern traces possible under connector
Pb-free and halogen-free compliant
Ni barrier prevents solder wicking
Rated current DC 0.35A per contact
Durability 20 mating cycles

Application scenarios

Computers
Office machines
Measuring devices
Telecommunication devices (Terminals, Mobile devices)
AV devices
Household applications
FA devices
