    APTCV60TLM99T3G [Microchip]

    APTCV60TLM99T3G
    APTCV60TLM99T3G

    Part No:

    APTCV60TLM99T3G

    Category:

    Power Supplies

    Manufacturer:

    Microchip

    Description:

    Three level inverter Power Module with Trench & Field Stop IGBT3 (Q2, Q3) and Super junction MOSFET (Q1, Q4).

    RoHS Status:

    Product FAQ

    1. Is APTCV60TLM99T3G available for RFQ?

    Yes. APTCV60TLM99T3G by Microchip is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

    2. Why is there no fixed price for APTCV60TLM99T3G?

    Pricing for APTCV60TLM99T3G can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

    3. What are the key specifications of APTCV60TLM99T3G?

    APTCV60TLM99T3G is a Microchip Power Supplies with Continuous Collector Current Igbt: 30A and Continuous Drain Current Mosfet: 17A. Review the product details or submit an RFQ if you need confirmation before purchase.

    4. How fast can I get a quote for APTCV60TLM99T3G?

    Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

    5. How soon can APTCV60TLM99T3G be shipped?

    If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

    6. Can you suggest alternatives to APTCV60TLM99T3G?

    Yes. If APTCV60TLM99T3G is unavailable, obsolete, or does not meet your required lead time, we can help check similar Microchip Power Supplies parts or compatible alternatives.

    RFQ

    Part Number:

    APTCV60TLM99T3G

    Manufacturer:

    Microchip

    Looking for Pricing? Contact us for volume pricing.

    IMPORTANT NOTICE

    Quotations are subject to stock availability and may vary with market conditions. Prices and lead times are not guaranteed until a purchase order is confirmed. Ensure your contact details are correct to avoid delays in response.

    Featured Product

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    Type
    Parameter
    Isolation Voltage
    4000V
    Operating Temperature
    -40°C ~ 175°C
    Storage Temperature
    -40°C ~ 125°C
    RoHS Status
    RoHS Compliant
    RoHS Status
    RoHS Compliant
    Case Temperature
    125°C
    Case Temperature Min
    -40°C
    Continuous Collector Current Igbt
    30A
    Continuous Drain Current Mosfet
    17A
    Mounting Torque
    2 to 3 N.m
    Ntc B Value
    3952 K
    Ntc Resistance 25c
    50kΩ
    Package Weight
    110 g
    Rated Voltage
    600V
    Rds On Mosfet
    99mΩ
    Thermal Resistance Diode
    1.2°C/W
    Thermal Resistance Igbt
    1.6°C/W
    Thermal Resistance Mosfet
    1.15°C/W
    Vce Sat Igbt Max
    1.9V
    Vce Sat Igbt Min
    1.5V

    Products Detail

    The module integrates Trench & Field Stop IGBT3 for Q2, Q3 and Super junction MOSFET for Q1, Q4. It features low voltage drop, low tail current, switching frequency up to 20 kHz, low leakage current, RBSOA and SCSOA rated for IGBTs, and ultra low RDSon, low Miller capacitance, ultra low gate charge, avalanche energy rated, very rugged for MOSFETs. Additional features include Kelvin emitter for easy drive, very low stray inductance, high level of integration, internal thermistor for temperature monitoring. Benefits include stable temperature behavior, very rugged, direct mounting to heatsink (isolated package), low junction to case thermal resistance, low profile, and RoHS compliance.

    Key Features

    • Q2, Q3 Trench + Field Stop IGBT3: Low voltage drop, Low tail current, Switching frequency up to 20 kHz, Low leakage current, RBSOA and SCSOA rated
    • Q1, Q4 Super junction MOSFET: Ultra low RDSon, Low Miller capacitance, Ultra low gate charge, Avalanche energy rated, Very rugged
    • Kelvin emitter for easy drive
    • Very low stray inductance
    • High level of integration
    • Internal thermistor for temperature monitoring
    • Stable temperature behavior
    • Very rugged
    • Direct mounting to heatsink (isolated package)
    • Low junction to case thermal resistance
    • Low profile
    • RoHS Compliant

    Application scenarios

    • Solar converter
    • Uninterruptible Power Supplies
