APTM10UM01FAG [Microchip]

Name: APTM10UM01FAG
Brand: Microchip
SKU: APTM10UM01FAG
Availability: InStock

Part No:

APTM10UM01FAG

Power Supplies

Manufacturer:

Microchip

Description:

100V Single Switch DSS MOSFET Power Module with typical RDSon of 1.5mΩ and continuous drain current of 860A at Tc=25°C.

RoHS Status:

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Isolation Voltage

4000V

Storage Temperature

-40°C ~ 125°C

Weight

300 g

RoHS Status

RoHS Compliant

RoHS Status

RoHS Compliant

Package

SP6

Ciss

60nF

Coss

23nF

Crss

8.8nF

Dv Dt Peak

5V/ns

EAR

50 mJ

EAS

3000 mJ

Products Detail

Single Switch DSS MOSFET Power Module featuring Power MOS V® FREDFETs with low RDSon, low input and Miller capacitance, low gate charge, avalanche energy rated, fast intrinsic diode, and very rugged. Includes Kelvin source for easy drive, very low stray inductance with symmetrical design and M5 power connectors. High level of integration with AlN substrate for improved thermal performance. Benefits include outstanding performance at high frequency operation, direct mounting to heatsink (isolated package), low junction to case thermal resistance, low profile, and RoHS compliance. Suitable for welding converters, switched mode power supplies, uninterruptible power supplies, and motor control.

Key Features

Power MOS V® FREDFETs
Low RDSon
Low input and Miller capacitance
Low gate charge
Avalanche energy rated
Fast intrinsic diode
Very rugged
Kelvin source for easy drive
Very low stray inductance
Symmetrical design
M5 power connectors
High level of integration
AlN substrate for improved thermal performance
Outstanding performance at high frequency operation
Direct mounting to heatsink (isolated package)
Low junction to case thermal resistance
Low profile
RoHS Compliant

Application scenarios

Welding converters
Switched Mode Power Supplies
Uninterruptible Power Supplies
Motor control
