APTM120UM70DAG Overview

As a result of avalanche breakdown, energy applied to the MOSFET is called avalanche energy, and the avalanche energy rating is 3200 mJ.CI refers to the capacitance between two input terminals on an op amp with either input grounded, and this device's maximum input capacitance is 43500pF @ 25V.In this device, the drain current (ID) is equal to the continuous current transistor can conduct.As a result of its turn-off delay time, which is 245 ns, the device has taken time to charge its input capacitance before drain current conduction begins.Input capacitance charge delays drain current conduction until the time it takes to charge input capacitance reaches 20 ns.Gate-source voltages (VGS) are voltages that fall across the gate-source terminal of FET transistors. VGS is sometimes 30VV.The transistor must receive a 1200V drain to source voltage (Vdss) in order to function.In addition to reducing power consumption, this device uses drive voltage (10V).

APTM120UM70DAG Features

the avalanche energy rating (Eas) is 3200 mJ
a continuous drain current (ID) of 171A
the turn-off delay time is 245 ns
a 1200V drain to source voltage (Vdss)

APTM120UM70DAG Applications

There are a lot of Microsemi Corporation
APTM120UM70DAG applications of single MOSFETs transistors.

• DC/DC converters
• Power Tools
• Motor Drives and Uninterruptible Power Supples
• Synchronous Rectification
• Battery Protection Circuit
• Telecom 1 Sever Power Supplies
• Industrial Power Supplies
• PFC stages, hard switching PWM stages and resonant switching
• PWM stages for e.g. PC Silverbox, Adapter, LCD & PDP TV,
• Lighting, Server, Telecom and UPS.
