APTM50AM17FG [Microchip]

APTM50AM17FG

Part No:

APTM50AM17FG

Category:Power Supplies

Manufacturer:Microchip

Description:

Package:-

RoHS Status:

Datasheet:

Production Status:

In Stock Status:

Specification

Type

Parameter

Factory Lead Time

36 Weeks

Mount

Chassis Mount, Screw

Mounting Type

Chassis Mount

Package / Case

SP6

Number of Pins

6

Transistor Element Material

SILICON

Operating Temperature

-40°C~150°C TJ

Packaging

Bulk

Published

2006

JESD-609 Code

e1

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

7

ECCN Code

EAR99

Terminal Finish

TIN SILVER COPPER

Additional Feature

AVALANCHE RATED

Max Power Dissipation

1.25kW

Terminal Position

UPPER

Terminal Form

UNSPECIFIED

Pin Count

7

JESD-30 Code

R-XUFM-X7

Number of Elements

2

Operating Mode

ENHANCEMENT MODE

Power Dissipation

1.25kW

Case Connection

ISOLATED

Turn On Delay Time

21 ns

Power - Max

1250W

FET Type

2 N-Channel (Half Bridge)

Transistor Application

SWITCHING

Vgs(th) (Max) @ Id

5V @ 10mA

Input Capacitance (Ciss) (Max) @ Vds

28000pF @ 25V

Gate Charge (Qg) (Max) @ Vgs

560nC @ 10V

Rise Time

38ns

Drain to Source Voltage (Vdss)

500V

Fall Time (Typ)

93 ns

Turn-Off Delay Time

75 ns

Continuous Drain Current (ID)

180A

Gate to Source Voltage (Vgs)

30V

Drain-source On Resistance-Max

0.017Ohm

DS Breakdown Voltage-Min

500V

Avalanche Energy Rating (Eas)

3000 mJ

FET Technology

METAL-OXIDE SEMICONDUCTOR

FET Feature

Standard

Radiation Hardening

No

RoHS Status

RoHS Compliant

Lead Free

Lead Free

Products Detail

No product details available

Key Features

No key features available

Application scenarios

No application scenarios available

Documents

Datasheets:

APTM50AM17FG Power Products Catalog
