ATSAMD20E14B-ANT [Microchip]

Name: ATSAMD20E14B-ANT
Brand: Microchip
SKU: ATSAMD20E14B-ANT
Availability: InStock

Part No:

ATSAMD20E14B-ANT

Unclassified

Manufacturer:

Microchip

Description:

SAMD20, 16KB Flash, 2KB RAM, ARM Cortex M0+, low power, 32-pin, low cost

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Part Family

Product FAQ

1. Is ATSAMD20E14B-ANT available for RFQ?

Yes. ATSAMD20E14B-ANT by Microchip is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

2. Why is there no fixed price for ATSAMD20E14B-ANT?

Pricing for ATSAMD20E14B-ANT can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

3. What are the key specifications of ATSAMD20E14B-ANT?

ATSAMD20E14B-ANT is a Microchip Unclassified with Operation Voltage Min.(V): 1.62 and Operation Voltage Max.(V): 3.63. Review the product details or submit an RFQ if you need confirmation before purchase.

4. How fast can I get a quote for ATSAMD20E14B-ANT?

Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

5. How soon can ATSAMD20E14B-ANT be shipped?

If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

6. Can you suggest alternatives to ATSAMD20E14B-ANT?

Yes. If ATSAMD20E14B-ANT is unavailable, obsolete, or does not meet your required lead time, we can help check similar Microchip Unclassified parts or compatible alternatives.

RFQ

Part Number:

ATSAMD20E14B-ANT

Manufacturer:

Microchip

Looking for Pricing? Contact us for volume pricing.

IMPORTANT NOTICE

Quotations are subject to stock availability and may vary with market conditions. Prices and lead times are not guaranteed until a purchase order is confirmed. Ensure your contact details are correct to avoid delays in response.

A low-power, high-performance Microchip's ARM® Cortex®-M0+ based flash microcontroller, the ATSAMD20E14 is ideal for a wide range of home automation, consumer, metering, and industrial applications. It features:

16KB of flash and 2KB of SRAM
Up to 48MHz operating frequency
Four serial communication modules (SERCOM) configurable as UART/USART, SPI or I²C, six 16-bit timer/counters, 32-bit Real Time clock and calendar, 10 PWM channels, one 10-channel 12-bit ADC, one 10-bit DAC
Support for up to 60 touch channels
1.62V to 3.63V power supply
Easy pin migration to SAMD20G and SAMD20J devices

Supported by MPLAB X IDE and MPLAB Harmony.

ARM Cortex-M0+ CPU running at up to 48MHz

Single-cycle hardware multiplier

16KB in-system self-programmable Flash

2KB SRAM memory

Power-on reset (POR) and brown-out detection (BOD)

Internal and external clock options with 48MHdigital frequency locked loop (DFLL48M) and 48MHto 96MHz

fractional digital phase locked loop (FDPLL96M)

External interrupt controller (EIC)

16 external interrupts

One non-maskable interrupt

Two-pin serial wire debug (SWD) programming, test and debugging interface

Idle and standby sleep modes

SleepWalking peripherals

8-channel event system

Six 16-bit timer/counters (TC)

32-bit real time counter (RTC) with clock/calendar function

Watchdog timer (WDT)

CRC-32 generator

USART with full-duplex and single-wire half-duplex configuration

I2C up to 40kHz

SPI

One 12-bit, 350ksps analog-to-digital converter (ADC), Differential and single-ended input

1/2x to 16x programmable gain stage

Automatic offset and gain error compensation

Oversampling and decimation in hardware to support 13-, 14-, 15- or 16-bit resolution

10-bit, 350ksps digital-to-analog converter (DAC)

Two analog comparators (AC) with window compare function

256-channel capacitive touch and proximity sensing

26 GPIO pins

32-pin TQFP, QFN

1.62V to 3.63V

Power Consumption: Down to 70µA/MHz in active mode

Power Consumption: Down to 8µA running the peripheral Touch Controller

–40 to +105°C
