LX7104ISF Overview

For optimal performance, this voltage regulator makes use of the Bulk package. In this voltage regulator, there are a total of 6 terminations. There is one type of analog IC that this voltage regulator is equipped with, and that is the SWITCHING REGULATOR type. In order to save space, this harley voltage regulator is available in the SOT-23-6 package. There are 1 outputs configured on this voltage regulator 12v. There are output pins on this DC DC switching regulator that generate Adjustable output. Surface Mount-mounting is compatible with this switching regulator. The operating temperature should be kept at -40°C~85°C TA when the voltage regulator 12v is in operation. This DC-DC switching regulator has a switching frequency of 1.4MHz. The voltage regulator can operate with a dc to dc voltage regulator's minimum input voltage of 4.5V. As a result, the output voltage of the voltage regulator 12v (Min/Fixed) is 0.81V. Voltage regulator has a maximum input voltage of 18V. In order to meet the operation requirements,voltage regulator is designed to provide a nominal input voltage of 12V. The voltage DC DC switching regulator can produce is 15V volts. There are 6 pins that are used for the operation of the voltage regulator 12v. The maximum output current reaches 1.5A A to meet the switching regulator operation requirements. 18V is the supply voltage for this DC-DC switching regulator.

LX7104ISF Features

1 outputs
6 pins
Operating supply voltage of 18V
