MCP47CMD22 is a dual channel, 12-bit, buffered voltage output Digital-to-Analog Converter (DAC) with MTP memory and an I²C Compatible Serial Interface. This device provides four different voltage reference options: device VDD, external VREF (Buffered or unbuffered) and internal bandgap. It offers 1 LSB Integral Non-Linearity (INL) with low power consumption and a fast settling time of 4 µs. This device has integrated MTP memory that can be written up to 32 times, for each specific register. It is suitable for consumer and industrial applications, such as set point or offset trimming, sensor calibrations, motor control applications and more.

For different resolutions and number of output channels, please check out our other parts in the MCP47CM family.

We welcome questions, comments and recommendations for improvements to this page - please contact us at: [email protected] if you have any; please mention the part number in the email subject header.

Voltage Reference Options
• Device VDD
• External VREF (buffered or unbuffered)
• Internal Bandgap (1.214V typ)

Output Gain Options:
• Unity (1x)
• 2x (when not using internal VDD as voltage source)

Power Down Modes
• Disconnects output buffer (High Impedance)
• Selection of VOUT pull-down resistors (100 kΩ or 1 kΩ)

Operating Voltage
• Full Specifications 2.7V to 5.5V
• Reduced Device Specifications 1.8V to 2.7V

Packages
• 16 Lead QFN (3mm x 3mm)
• 10 Lead DFN (3mm x 3mm)
• 10 Lead MSOP
