MCP8063-E/MD [Microchip]

The MCP8063 is a highly integrated sinusoidal sensorless driver for brushless DC motors. It features 180° sinusoidal drive for high torque output and silent operation. It is intended to cover a wide range of motor characteristics, while requiring no external tuning from the user. Speed control can be achieved through either power supply or pulse-width-modulation (using the PWM digital input pin). The compact packaging and minimum bill-of-material (BOM), it is best suited for fan applications that require high efficiency and low acoustic noise. Frequency generator output is also included, enabling for precision speed control in closed-loop applications. The MCP8063 driver includes a lockup protection mode, which turns-off the output current when the motor is under lock condition, and an automatic recovery that enables the fan to run when the lock condition is removed. Automotive AEC-Q100 Qualified, PPAP Available Upon Request.

• Automotive AEC-Q100 Qualified, PPAP Available Upon Request
• Position Sensorless BLDC Drivers (No Hall Sensor Required)
• 23 kHz PWM Output Frequency
• 180° Sinusoidal Drive For High Efficiency And Low Acoustic Noise
• Support 2V to 14V Power Supplies
• Speed Control Through Power Supply and/or PWM
• Built-in 1.5A Over Current Limitation
• Built-in Frequency Generator (FG Output Signal)
• Built-in Lock-up Protection And Automatic Recovery Circuit
• Built-in Thermal Shutdown Protection
• No External Tuning Required
