    PD70101EVB3F [Microchip]

    PD70101EVB3F
    PD70101EVB3F

    Part No:

    PD70101EVB3F

    Category:

    Development Tools

    Manufacturer:

    Microchip

    Description:

    Power over Ethernet 802.3af/at PD Controller

    Datasheet:

    Product FAQ

    1. Is PD70101EVB3F available for RFQ?

    Yes. PD70101EVB3F by Microchip is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

    2. Why is there no fixed price for PD70101EVB3F?

    Pricing for PD70101EVB3F can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

    3. What are the key specifications of PD70101EVB3F?

    PD70101EVB3F is a Microchip Development Tools with Thermal Resistance Junction To Ambient: 42.5°C/W and Junction Temperature: 150°C. Review the product details or submit an RFQ if you need confirmation before purchase.

    4. How fast can I get a quote for PD70101EVB3F?

    Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

    5. How soon can PD70101EVB3F be shipped?

    If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

    6. Can you suggest alternatives to PD70101EVB3F?

    Yes. If PD70101EVB3F is unavailable, obsolete, or does not meet your required lead time, we can help check similar Microchip Development Tools parts or compatible alternatives.

    RFQ

    Part Number:

    PD70101EVB3F

    Manufacturer:

    Microchip

    Looking for Pricing? Contact us for volume pricing.

    IMPORTANT NOTICE

    Quotations are subject to stock availability and may vary with market conditions. Prices and lead times are not guaranteed until a purchase order is confirmed. Ensure your contact details are correct to avoid delays in response.

    Featured Product

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    Type
    Parameter
    Junction Temperature
    150°C
    Storage Temperature
    -65°C ~ 150°C
    Thermal Resistance Junction To Ambient
    42.5°C/W
    VPP Max
    100V
    VSW Max
    100V
    Vcc
    7V

    Products Detail

    The PD70101 and PD70201 devices are integrated Powered Device (PD) interface and PWM controllers for DC-DC converters in IEEE802.3af and IEEE802.3at applications. PD70101 supports IEEE802.3af or IEEE802.3at Type 1, while PD70201 also supports Type 2 and 4-pair applications up to 47.7 W. Features include detection and classification, internal MOSFET switch, gate drivers, peak current mode control, soft-start, UVLO, and low power mode operation.

    Key Features

    • IEEE802.3af and IEEE802.3at compliant
    • Support for 4-pair applications of up to 47.7 W with a single IC
    • Two-events classification identification with a level signal indicating Type 1 or Type 2 PSE
    • Less than 10 µA (typical) offset current during detection
    • Signature resistor is disconnected upon detection
    • Programmable classification setting with a single resistor
    • Integrated 0.6 Ω isolating MOSFET switch with inrush current limit
    • Power off DC-DC input capacitor discharge
    • 100 kHz to 500 kHz adjustable DC-DC switching frequency
    • DC-DC frequency can be synchronized to external clock
    • Supports low power mode operation for higher efficiency 50% maximum duty cycle
    • Soft-start circuit to control the output voltage rise time
    • Two out-of-phase driver stages for efficient synchronous rectification or active clamp
    • PoE port input UVLO with programmable threshold and hysteresis
    • Internal differential amplifier simplifying non-isolated step down converter
    • Over load and short circuit protection

    Application scenarios

    • IEEE802.3at and IEEE802.3af powered devices such as IP phones
    • WLAN access points
    • and network cameras; 48 V input telcom/networks hot swappable power supply

    Documents

    Datasheets:

    PD70101, PD70201 Datasheet
