2N3108 [Onsemi]

2N3108 Overview

As explained above, DC current gain takes into account the rate at which the base current flows through the collector current; therefore, DC current gain for this device is 40 @ 150mA1V.In VCE saturation, Ic is at its maximum value (saturated), and the vce saturation (Max) is 1V @ 100mA, 1A.This product comes in a TO-39 device package from the supplier.Device displays Collector Emitter Breakdown (60V maximal voltage).

2N3108 Features

the DC current gain for this device is 40 @ 150mA1V
the vce saturation(Max) is 1V @ 100mA, 1A
the supplier device package of TO-39

2N3108 Applications

There are a lot of ON Semiconductor
2N3108 applications of single BJT transistors.

• Inverter
• Interface
• Driver
• Muting
