KA1458D [Onsemi]

KA1458D Overview

There is a SOP case in which the instrumentation amplifier is packaged. Buffer amps of this type are called OPERATIONAL AMPLIFIER-types. The number of terminations is approaching the 8 mark. The total number of pins on linear amplifier is 8. The linear amplifier should be run at 15V at all times, so please keep that in mind when using it. In order to be more specific, this instrumentation amplifier is one of the types of Operational Amplifier devices. 8 pins are included on the operational amplifiers. As far as the input offset voltage is concerned, linear amplifier rates at 10mV. It is possible to operate this buffer amplifier from a supply current of 2.3mA . There should be no change in the voltage gain. In order for this buffer op amp to function, it should have a temperature of at least 0°C degrees Celsius. At temperatures greater than 70°C, op amp should not be used. There is a rating of 2 for the operating supply voltage of the buffer op amp. As a general rule, you should conduct this electronic component under dual supply voltages of 18V volts.

KA1458D Features

8 Pins
supply voltage of 15V
106.02dB voltage gain

KA1458D Applications

There are a lot of Fairchild (ON Semiconductor)
KA1458D Instrumentational OP Amps applications.

• Subtraction operation circuits
• single/dual op amp sum and difference circuits
• Integrator circuits
• Differentiator circuits
• Logarithmic operation circuits
• Exponential operation circuits
• Multiplication circuits
• Division circuits
• Precision measurement
• Power control
