16SEF180M [Panasonic]

Name: 16SEF180M
Brand: Panasonic
SKU: 16SEF180M
Availability: InStock

Part No:

16SEF180M

Capacitors

Manufacturer:

Panasonic

Description:

Conductive Polymer Aluminum Solid Capacitors, Radial Lead Type, Series: SEF.

RoHS Status:

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Capacitance Tolerance

±20%

Operating Temperature

-55°C ~ +125°C

RoHS Status

RoHS Compliant

RoHS Status

RoHS Compliant

16SEF1000M Allowable Ripple Current

5400 mAr.m.s.

16SEF1000M ESR

12mΩ

16SEF1000M F

5.0 mm

16SEF1000M FD

10.0 mm

16SEF1000M Fd

0.6 mm

16SEF1000M L

13.0 mm

16SEF1000M LC

3200µA

16SEF1000M Rated Capacitance

1000µF

16SEF1000M Rated Voltage

16V.DC

16SEF1000M Ripple Current

1700 mAr.m.s.

16SEF1000M Tan D

0.12

16SEF180M Allowable Ripple Current

3300 mAr.m.s.

16SEF180M ESR

22mΩ

16SEF180M F

2.5 mm

16SEF180M FD

6.3 mm

16SEF180M Fd

0.5 mm

16SEF180M L

6.0 mm

16SEF180M LC

576µA

16SEF180M Rated Capacitance

180µF

16SEF180M Rated Voltage

16V.DC

16SEF180M Ripple Current

1040 mAr.m.s.

16SEF180M Tan D

0.12

16SEF270M Allowable Ripple Current

3300 mAr.m.s.

16SEF270M ESR

22mΩ

16SEF270M F

3.5 mm

16SEF270M FD

8.0 mm

16SEF270M Fd

0.5 mm

16SEF270M L

7.0 mm

16SEF270M LC

864µA

16SEF270M Rated Capacitance

270µF

16SEF270M Rated Voltage

16V.DC

16SEF270M Ripple Current

1040 mAr.m.s.

16SEF270M Tan D

0.12

16SEF560M Allowable Ripple Current

4950 mAr.m.s.

16SEF560M ESR

14mΩ

16SEF560M F

3.5 mm

16SEF560M FD

8.0 mm

16SEF560M Fd

0.6 mm

16SEF560M L

12.0 mm

16SEF560M LC

1792µA

16SEF560M Rated Capacitance

560µF

16SEF560M Rated Voltage

16V.DC

16SEF560M Ripple Current

1560 mAr.m.s.

16SEF560M Tan D

0.12

20SEF120M Allowable Ripple Current

3200 mAr.m.s.

20SEF120M ESR

25mΩ

20SEF120M F

2.5 mm

20SEF120M FD

6.3 mm

20SEF120M Fd

0.5 mm

20SEF120M L

6.0 mm

20SEF120M LC

480µA

20SEF120M Rated Capacitance

120µF

20SEF120M Rated Voltage

20V.DC

20SEF120M Ripple Current

1010 mAr.m.s.

20SEF120M Tan D

0.12

20SEF180M Allowable Ripple Current

3200 mAr.m.s.

20SEF180M ESR

25mΩ

20SEF180M F

3.5 mm

20SEF180M FD

8.0 mm

20SEF180M Fd

0.5 mm

20SEF180M L

7.0 mm

20SEF180M LC

720µA

20SEF180M Rated Capacitance

180µF

20SEF180M Rated Voltage

20V.DC

20SEF180M Ripple Current

1010 mAr.m.s.

20SEF180M Tan D

0.12

20SEF390M Allowable Ripple Current

4950 mAr.m.s.

20SEF390M ESR

14mΩ

20SEF390M F

3.5 mm

20SEF390M FD

8.0 mm

20SEF390M Fd

0.6 mm

20SEF390M L

12.0 mm

20SEF390M LC

1560µA

20SEF390M Rated Capacitance

390µF

20SEF390M Rated Voltage

20V.DC

20SEF390M Ripple Current

1560 mAr.m.s.

20SEF390M Tan D

0.12

20SEF560M Allowable Ripple Current

5400 mAr.m.s.

20SEF560M ESR

12mΩ

20SEF560M F

5.0 mm

20SEF560M FD

10.0 mm

20SEF560M Fd

0.6 mm

20SEF560M L

13.0 mm

20SEF560M LC

2240µA

20SEF560M Rated Capacitance

560µF

20SEF560M Rated Voltage

20V.DC

20SEF560M Ripple Current

1700 mAr.m.s.

20SEF560M Tan D

0.12

25SEF180M Allowable Ripple Current

4650 mAr.m.s.

25SEF180M ESR

16mΩ

25SEF180M F

3.5 mm

25SEF180M FD

8.0 mm

25SEF180M Fd

0.6 mm

25SEF180M L

12.0 mm

25SEF180M LC

900µA

25SEF180M Rated Capacitance

180µF

25SEF180M Rated Voltage

25V.DC

25SEF180M Ripple Current

1470 mAr.m.s.

25SEF180M Tan D

0.12

25SEF330M Allowable Ripple Current

5000 mAr.m.s.

25SEF330M ESR

14mΩ

25SEF330M F

5.0 mm

25SEF330M FD

10.0 mm

25SEF330M Fd

0.6 mm

25SEF330M L

13.0 mm

25SEF330M LC

1650µA

25SEF330M Rated Capacitance

330µF

25SEF330M Rated Voltage

25V.DC

25SEF330M Ripple Current

1580 mAr.m.s.

25SEF330M Tan D

0.12

25SEF56M Allowable Ripple Current

2800 mAr.m.s.

25SEF56M ESR

30mΩ

25SEF56M F

2.5 mm

25SEF56M FD

6.3 mm

25SEF56M Fd

0.5 mm

25SEF56M L

6.0 mm

25SEF56M LC

280µA

25SEF56M Rated Capacitance

56µF

25SEF56M Rated Voltage

25V.DC

25SEF56M Ripple Current

880 mAr.m.s.

25SEF56M Tan D

0.12

25SEF82M Allowable Ripple Current

3000 mAr.m.s.

25SEF82M ESR

28mΩ

25SEF82M F

3.5 mm

25SEF82M FD

8.0 mm

25SEF82M Fd

0.5 mm

25SEF82M L

7.0 mm

25SEF82M LC

410µA

25SEF82M Rated Capacitance

82µF

25SEF82M Rated Voltage

25V.DC

25SEF82M Ripple Current

940 mAr.m.s.

25SEF82M Tan D

0.12

35SEF120M Allowable Ripple Current

4400 mAr.m.s.

35SEF120M ESR

18mΩ

35SEF120M F

5.0 mm

35SEF120M FD

10.0 mm

35SEF120M Fd

0.6 mm

35SEF120M L

13.0 mm

35SEF120M LC

840µA

35SEF120M Rated Capacitance

120µF

35SEF120M Rated Voltage

35V.DC

35SEF120M Ripple Current

1390 mAr.m.s.

35SEF120M Tan D

0.12

35SEF22M Allowable Ripple Current

2600 mAr.m.s.

35SEF22M ESR

35mΩ

35SEF22M F

2.5 mm

35SEF22M FD

6.3 mm

35SEF22M Fd

0.5 mm

35SEF22M L

6.0 mm

35SEF22M LC

154µA

35SEF22M Rated Capacitance

22µF

35SEF22M Rated Voltage

35V.DC

35SEF22M Ripple Current

820 mAr.m.s.

35SEF22M Tan D

0.12

35SEF39M Allowable Ripple Current

2800 mAr.m.s.

35SEF39M ESR

30mΩ

35SEF39M F

3.5 mm

35SEF39M FD

8.0 mm

35SEF39M Fd

0.5 mm

35SEF39M L

7.0 mm

35SEF39M LC

273µA

35SEF39M Rated Capacitance

39µF

35SEF39M Rated Voltage

35V.DC

35SEF39M Ripple Current

880 mAr.m.s.

35SEF39M Tan D

0.12

35SEF82M Allowable Ripple Current

4000 mAr.m.s.

35SEF82M ESR

20mΩ

35SEF82M F

3.5 mm

35SEF82M FD

8.0 mm

35SEF82M Fd

0.6 mm

35SEF82M L

12.0 mm

35SEF82M LC

574µA

35SEF82M Rated Capacitance

82µF

35SEF82M Rated Voltage

35V.DC

35SEF82M Ripple Current

1260 mAr.m.s.

35SEF82M Tan D

0.12

Products Detail

High voltage (35 V.DC max.) and large capacitance (1000 μF max.) conductive polymer aluminum solid capacitors. RoHS compliant and halogen free. Category temperature range: -55°C to +125°C. Rated voltage range: 16 V.DC to 35 V.DC. Rated capacitance range: 22 μF to 1000 μF depending on size code. Capacitance tolerance: ±20% (120 Hz / +20°C).

Key Features

High voltage (35 V.DC max.), Large capacitance (1000 μF max.), RoHS compliance, Halogen free

Documents

Datasheets:

SEF Series Datasheet*Conductive Poly Alum Caps, Part Number Guide OS-CON? Capacitors Product Catalog SVPK, SVF, SEF, OS-CON? Series, Prod Info Conductive Poly Alum Solid Caps, Product Guide
