NN30331A-VB [Panasonic]

Name: NN30331A-VB
Brand: Panasonic
SKU: NN30331A-VB
Availability: InStock

Part No:

NN30331A-VB

Power Management ICs

Manufacturer:

Panasonic

Description:

High-Speed Response DC-DC Step Down Regulator NN30331A is a synchronous DC-DC Step down Circuit that employs Hysteretic Control System Regulator.

Datasheet:

Product FAQ

1. Is NN30331A-VB available for RFQ?

Yes. NN30331A-VB by Panasonic is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

2. Why is there no fixed price for NN30331A-VB?

Pricing for NN30331A-VB can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

3. What are the key specifications of NN30331A-VB?

NN30331A-VB is a Panasonic Power Management ICs with Thermal Resistance Junction To Ambient: 50.4°C/W and High Side Mosfet On Resistance: 20mΩ (typ). Review the product details or submit an RFQ if you need confirmation before purchase.

4. How fast can I get a quote for NN30331A-VB?

Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

5. How soon can NN30331A-VB be shipped?

If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

6. Can you suggest alternatives to NN30331A-VB?

Yes. If NN30331A-VB is unavailable, obsolete, or does not meet your required lead time, we can help check similar Panasonic Power Management ICs parts or compatible alternatives.

RFQ

Part Number:

NN30331A-VB

Manufacturer:

Panasonic

Looking for Pricing? Contact us for volume pricing.

IMPORTANT NOTICE

Quotations are subject to stock availability and may vary with market conditions. Prices and lead times are not guaranteed until a purchase order is confirmed. Ensure your contact details are correct to avoid delays in response.

The NN30331A is a synchronous DC-DC step-down regulator featuring a hysteretic control system with integrated high-side (20 mΩ typ) and low-side (6 mΩ typ) MOSFETs for high efficiency at 8 A output. It supports input voltages from 4.5 V to 24 V (AVIN/PVIN) and 4.5 V to 5.5 V (V5), with adjustable output voltage from 0.75 V to 3.6 V. Key features include selectable switching frequencies (430 kHz/630 kHz), adjustable soft start, low-power mode for light-load efficiency, and comprehensive protection circuits (UVLO, TSD, UVD, OVD, SCP, OCP). The device provides power-good indication and comes in a compact 24-pin QFN package (4 mm × 4 mm × 0.7 mm).
