LYT7504D [Power Integrations]

Name: LYT7504D
Brand: Power Integrations
SKU: LYT7504D

Part No:

LYT7504D

Category:

Driver ICs

Manufacturer:

Power Integrations

Description:

PMIC LYTSwitch?-7 Series 8 Pin 8-SOIC (0.154, 3.90mm Width)

Package:

-

RoHS Status:

Datasheet:

Production Status:

In Stock Status:

Specification

Type

Parameter

Factory Lead Time

6 Weeks

Mounting Type

Surface Mount

Package / Case

8-SOIC (0.154, 3.90mm Width)

Number of Pins

8

Operating Temperature

-40°C~150°C TJ

Packaging

Tube

Published

2016

Pbfree Code

yes

Part Status

Discontinued

Moisture Sensitivity Level (MSL)

1 (Unlimited)

ECCN Code

EAR99

Type

AC DC Offline Switcher

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Number of Outputs

1

Output Voltage

60V

Topology

Step-Down (Buck)

Internal Switch(s)

Yes

Dimming

Triac

Switching Frequency

20kHz

Voltage - Supply (Max)

308VAC

Voltage - Supply (Min)

90VAC

Min Input Voltage (AC)

90V

Max Input Voltage (AC)

308V

REACH SVHC

No SVHC

RoHS Status

RoHS Compliant

Products Detail

LYT7504D Overview

Board space is saved by its 8-SOIC (0.154, 3.90mm Width) package.This LED driver has 1 outputs.Surface Mount is used for mounting.This emerges as a AC DC Offline Switcher with high efficiency and reliability.The led light driver is capable of working normally at -40°C~150°C TJ.It is configured with 8 pins as its base.Undetermined failures will occur if the voltage supply is less than 90VAC.The supply voltage is optimized to offer a maximum value of 308VAC.It's possible for this electronic component to fully function when the switching frequency is maintained at 20kHz.There are many applications for this LED driver belonging to the LYTSwitch?-7 series.There is 60V voltage at the output terminal.
