BA9743AFV-E2 Overview

In the 16-LSSOP (0.173, 4.40mm Width) package, the switching controller meets most application requirements. There is sufficient capacity to generate switching controller for outputs 2. There is a Tape & Reel (TR) solid enclosure around the pmic. With this function, you can deal with Transistor Driver dc switching's outputs (s). DC control operates at 3.6V~35V volts and has 3.6V~35V supply voltage. Suitable for working in an dc switcher that has a -40°C~85°C TA. It can switch at 10kHz~800kHz. As it has a Surface Mount value, it can be used for general dc dc regulator. To provide efficient switching control, Dead Time Control, Soft Start is included in the dcdc regulator. A DUAL SWITCHING CONTROLLER analog integrated circuit is connected to the switch converters. DUAL are the position of the terminal of the switching converters. Various 16 terminations. This dc dc converter ic uses a variety of control techniques, including PULSE WIDTH MODULATION. There is a DC switcher's nominal voltage of 6V. In addition to "BA9743", there are other relevant dc to dc converter ics you can find. There are 16 pins on switching converter. Specifically, switching converter falls under the Switching Regulator or Controllers category. It is recommended that the dc dc voltage regulator's minimum input voltage be 3.6V. DC regulator outputs 35V voltage based on test statistics. A starting point for a project is to note down the dc dc regulator's usual output current, which is 100mA. Voltage regulator dc to dc is designed to operate at 65 % duty cycle during power-ups and power-downs to ensure reliability. Because of DC switcher's Surface Mount, it is suitable for most prototype designs and applications. DC regulator800kHz has the maximum frequency. An output current greater than 100mA cannot be provided by the dc switcher.

BA9743AFV-E2 Features

Transistor Driver Outputs
Switching Frequency: 10kHz~800kHz
Dead Time Control, Soft Start
PULSE WIDTH MODULATION
Max Duty Cycle: 65 %
