STR-A6069HD [SANKEN]

Name: STR-A6069HD
Brand: SANKEN
SKU: STR-A6069HD
Availability: InStock

Part No:

STR-A6069HD

Category:

Power Supplies

Manufacturer:

SANKEN

Description:

The STR-A6000 series are power ICs for switching power supplies, incorporating a MOSFET and a current mode PWM controller IC.

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Operating Temperature

-20°C ~ 125°C

Package

DIP8

Ovp Threshold Voltage Max

32V

Ovp Threshold Voltage Min

26V

Thermal Resistance Channel To Case

22°C/W

Thermal Shutdown Temperature

135°C

Vcc Start Max

16.8V

Vcc Start Min

13.8V

Vcc Stop Max

8.9V

Vcc Stop Min

7.3V

Products Detail

The STR-A6000 series are power ICs for switching power supplies, incorporating a MOSFET and a current mode PWM controller IC. The low standby power is accomplished by automatic switching between PWM operation in normal conditions and burst-oscillation under light load. It achieves high cost-performance power supply systems with minimal external components. Features include current mode PWM control, brown-in/brown-out functions, auto standby, random switching, slope compensation, leading edge blanking, bias assist, audible noise suppression during standby, and comprehensive protections (OCP, OLP, OVP, TSD).

Key Features

Current Mode Type PWM Control
Brown-In and Brown-Out function
Auto Standby Function
Operation Mode: PWM (Normal), Burst Oscillation (Standby)
Random Switching Function
Slope Compensation Function
Leading Edge Blanking Function
Bias Assist Function
Audible Noise Suppression during Standby
Protections: Overcurrent (OCP), Overload (OLP), Overvoltage (OVP), Thermal Shutdown (TSD)

Application scenarios

Low power AC/DC adapter
White goods
Auxiliary power supply
OA
AV and industrial equipment

Documents

Datasheets:

STR-A60xx Series

Product FAQ

1. Is STR-A6069HD available for RFQ?

Yes. STR-A6069HD by SANKEN is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

2. Why is there no fixed price for STR-A6069HD?

Pricing for STR-A6069HD can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

3. What are the key specifications of STR-A6069HD?

STR-A6069HD is a SANKEN Power Supplies with Thermal Resistance Channel To Case: 22°C/W and Thermal Shutdown Temperature: 135°C. Review the product details or submit an RFQ if you need confirmation before purchase.

4. How fast can I get a quote for STR-A6069HD?

Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

5. How soon can STR-A6069HD be shipped?

If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

6. Can you suggest alternatives to STR-A6069HD?

Yes. If STR-A6069HD is unavailable, obsolete, or does not meet your required lead time, we can help check similar SANKEN Power Supplies parts or compatible alternatives.
