NUCLEO-F446RE Description

The STM32 NUCLEO-F446RE board provides an affordable and flexible way for users to try out new concepts and build prototypes by choosing from the various combinations of performance and power consumption features, provided by the STM32 microcontroller. For the compatible boards, the external SMPS significantly reduces power consumption in Run mode. The ARDUINO® Uno V3 connectivity support and the ST morpho headers allow the easy expansion of the functionality of the STM32 Nucleo open development platform with a wide choice of specialized shields.

NUCLEO-F446RE Features

STM32 microcontroller in LQFP64 or LQFP48 package

1 user LED shared with ARDUINO®

1 user and 1 reset push-buttons

32.768 kHz crystal oscillator

Flexible power-supply options: ST-LINK USB VBUS or external sources

On-board ST-LINK debugger/programmer with USB re-enumeration capability: mass storage, Virtual COM port, and debug port

NUCLEO-F446RE Applications

Automotive

Advanced driver assistance systems (ADAS)

Enterprise systems

Datacenter & enterprise computing

Personal electronics

Home theater & entertainment
