MA1206DIN [TDK]

Name: MA1206DIN
Brand: TDK
SKU: MA1206DIN
Availability: InStock

Part No:

MA1206DIN

Power Condition

Manufacturer:

TDK

Description:

MA/MX12 Series 6A to 30A, 250VAC EMI Filters

RoHS Status:

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Rated Voltage

250VAC or VDC

Operating Humidity

30 to 95% RH (non condensing)

Leakage Current

1mA max at 250VAC 60Hz

Test Voltage

2500VAC (terminals to case) for 1 min at 25C, 70% RH

Storage Humidity

10 to 95% RH (non condensing)

Isolation Resistance

100MΩ minimum at 70% RH (terminals to case, 500VDC)

Rated Current

6A ~ 30A

Operating Temperature

-40°C ~ +85°C

Vibration

10-55-10Hz sweep for 1 min. Amplitude 1.5mm constant (max 88.3m/s2, X, Y, Z 2 hours each)

Storage Temperature

-40°C ~ +85°C

Products Detail

The MA/MX12 Series are EMI filters available in 6A to 30A current ratings with 250VAC/VDC voltage rating. MA series offers single-stage low-frequency attenuation (150-500kHz), while MX series provides two-stage wide-band attenuation (150kHz-30MHz). Features include captive screws for ring tag terminals, chassis or DIN rail mounting, safety agency approvals, and RoHS compliance. Specifications include 2500VAC test voltage, 100MΩ isolation resistance, 1mA max leakage current, 30°C max temperature rise, and operation from -40°C to +85°C.

Key Features

Easy Connection and Installation
Captive screws accepting ring tag terminals
Chassis or DIN Rail mount
Safety Agency Approved, RoHS Compliant
MA series (single stage) Low frequency attenuation
MX series (two stage) Wide band attenuation

Documents

Datasheets:

MA,MX12 Series

Product FAQ

1. Is MA1206DIN available for RFQ?

Yes. MA1206DIN by TDK is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

2. Why is there no fixed price for MA1206DIN?

Pricing for MA1206DIN can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

3. What are the key specifications of MA1206DIN?

MA1206DIN is a TDK Power Condition with Operating Temperature: -40°C ~ +85°C and Isolation Resistance: 100MΩ minimum at 70% RH (terminals to case, 500VDC). Review the product details or submit an RFQ if you need confirmation before purchase.

4. How fast can I get a quote for MA1206DIN?

Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

5. How soon can MA1206DIN be shipped?

If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

6. Can you suggest alternatives to MA1206DIN?

Yes. If MA1206DIN is unavailable, obsolete, or does not meet your required lead time, we can help check similar TDK Power Condition parts or compatible alternatives.
