    CC2533DK-RF4CE-BA [Texas Instruments]

    CC2533DK-RF4CE-BA
    CC2533DK-RF4CE-BA

    Part No:

    CC2533DK-RF4CE-BA

    Category:

    Development Tools

    Manufacturer:

    Texas Instruments

    Description:

    The CC2533 is an optimized system-on-chip (SoC) solution for IEEE 802.15.4 based remote-control systems.

    Datasheet:

    Product FAQ

    1. Is CC2533DK-RF4CE-BA available for RFQ?

    Yes. CC2533DK-RF4CE-BA by Texas Instruments is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

    2. Why is there no fixed price for CC2533DK-RF4CE-BA?

    Pricing for CC2533DK-RF4CE-BA can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

    3. What are the key specifications of CC2533DK-RF4CE-BA?

    CC2533DK-RF4CE-BA is a Texas Instruments Development Tools with Absolute Max Supply Voltage: -0.3V ~ 3.9V and Active Mode Tx 0dbm Current: 28.5mA. Review the product details or submit an RFQ if you need confirmation before purchase.

    4. How fast can I get a quote for CC2533DK-RF4CE-BA?

    Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

    5. How soon can CC2533DK-RF4CE-BA be shipped?

    If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

    6. Can you suggest alternatives to CC2533DK-RF4CE-BA?

    Yes. If CC2533DK-RF4CE-BA is unavailable, obsolete, or does not meet your required lead time, we can help check similar Texas Instruments Development Tools parts or compatible alternatives.

    RFQ

    Part Number:

    CC2533DK-RF4CE-BA

    Manufacturer:

    Texas Instruments

    Looking for Pricing? Contact us for volume pricing.

    IMPORTANT NOTICE

    Quotations are subject to stock availability and may vary with market conditions. Prices and lead times are not guaranteed until a purchase order is confirmed. Ensure your contact details are correct to avoid delays in response.

    Featured Product

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    Type
    Parameter
    Operating Temperature
    -40°C ~ 125°C
    Supply Voltage
    2V ~ 3.6V
    Package
    QFN40 (6x6 mm)
    Storage Temperature
    -40°C ~ 125°C
    Absolute Max Supply Voltage
    -0.3V ~ 3.9V
    Active Mode Rx Current
    25mA
    Active Mode Tx 0dbm Current
    28.5mA
    Boost Mode Output Power
    7 dBm
    Cpu
    8051
    ESD Charged Device Model
    500V
    ESD Human Body Model
    2kV
    ESD Machine Model
    200V
    Flash Size Max
    96 KB
    Io Pins
    23
    Output Power
    7 dBm
    Output Power Typical
    4.5 dBm
    Power Mode1 Current
    0.2mA
    Power Mode2 Current
    1mA
    Power Mode3 Current
    0.5mA
    Radio Baud Rate
    250 kbps
    Radio Chip Rate
    2 MChip/s
    Ram Size Max
    6 KB
    Receiver Sensitivity
    -93 dBm
    Rf Frequency Max
    2507MHz
    Rf Frequency Min
    2394MHz

    Products Detail

    The CC2533 combines a leading RF transceiver with a single-cycle 8051 compliant CPU, up to 96-KB in-system programmable flash memory, up to 6-KB RAM, and many other powerful features. It has efficient power modes with RAM and register retention below 1 µA, making it highly suited for low-duty-cycle systems. Combined with the RemoTI stack, it provides a robust ZigBee RF4CE remote-control solution. The device exists in three memory configurations: CC2533F32 (32-KB Flash, 4-KB RAM), CC2533F64 (64-KB Flash, 4-KB RAM), and CC2533F96 (96-KB Flash, 6-KB RAM).

    Key Features

    • RF: 2.4-GHz IEEE 802.15.4 Compliant RF Transceiver, Excellent Receiver Sensitivity, Programmable Output Power up to 4.5 dBm, Boost-Mode TX at 7 dBm, Single Crystal for Asynchronous Networks, Space-Saving 6-mm × 6-mm QFN40 Package. Low Power: Active-Mode RX 25 mA, Active Mode TX 28.5 mA, Power Mode 1 0.2 mA, Power Mode 2 1 mA, Power Mode 3 0.5 mA, Wide Supply-Voltage Range (2V–3.6V). Microcontroller: High-Performance Low-Power 8051 Core, 64/96 KB Flash, 4/6 KB RAM, Hardware Debug Support. Peripherals: Five-Channel DMA, IEEE 802.15.4 MAC Timer, IR Generation Circuitry, CSMA/CA Hardware Support, AES Security Coprocessor, Two USARTs (UART/SPI), I2C Interface, 23 General-Purpose I/O Pins, Watchdog Timer, Battery Monitor, Random Number Generator. Development Tools: CC2533 Development Kit, SmartRF Software, Packet Sniffer, IAR Embedded Workbench Support

    Application scenarios

    • ZigBee RF4CE Remote Control Target and Device
    • 2.4-GHz IEEE 802.15.4 Systems Based on TIMAC or SimpliciTI Network Protocol
    • Consumer Electronics
    • Electronic Shelf Labeling

    Documents

    Datasheets:

    CC2533
