COP8C [Texas Instruments]

Name: COP8C
Brand: Texas Instruments
SKU: COP8C
Availability: InStock

Part No:

COP8C

Unclassified

Manufacturer:

Texas Instruments

Description:

COP8SG Family 8-Bit CMOS ROM Based and OTP Microcontrollers with 8k to 32k Memory, Two Comparators and USART

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Allowable Sink Current D

15mA

Allowable Sink Current Others

3mA

Cki Resistance

5 to 11kΩ

D Output Sink Current

10mA

D Output Source Current

-0.4mA

ESD Protection

2kV

Eprom Data Retention

>29 years

G Port Input Hysteresis

0.25Vcc

Halt Current Typ

<4µA

Hi Z Input Leakage

±2µA

Input Capacitance

7pF

Input Pullup Current

-40 to -250µA

Input Voltage High Cki

0.7Vcc

Input Voltage High Reset

0.8Vcc

Input Voltage Low Cki

0.2Vcc

Input Voltage Low Reset

0.2Vcc

Instruction Cycle Time

0.67µs

Internal Bias Resistor

0.5 to 2MΩ

Io Pins

24/36/40

Load Capacitance D2

1000pF

Maximum Input Current

±200mA

Operating Temperature

-40°C ~ +85°C

Package

28SOIC, 40PDIP, 44PLCC, LQFP, WQFN

Power Supply Ripple

0.1V

Program Memory

8k to 32k ROM or OTP

Push Pull Sink Current

1.6mA

Push Pull Source Current

-0.4mA

Ram

256 or 512 bytes

Ram Retention Voltage

2.0V

Reset Voltage

0.25V

Storage Temperature

-65°C ~ +140°C

Supply Current

9.0mA

Supply Voltage

2.7V ~ 5.5V

Tri State Leakage

±2µA

Vcc Rise Time

12 µs

Weak Pull Up Source Current

-10.0 to -110µA

Products Detail

The COP8SG Family ROM and OTP based microcontrollers are highly integrated COP8™ Feature core devices with 8k to 32k memory and advanced features including Analog comparators, and zero external components. These single-chip CMOS devices are suited for more complex applications requiring a full-featured controller with larger memory, low EMI, two comparators, and a full-duplex USART. COP8SGx7 devices are 100% form-fit-function compatible OTP versions for use in production or development of the COP8SGx5 ROM. Family features include an 8-bit memory mapped architecture, 15 MHz CKI with 0.67 μs instruction cycle, 14 interrupts, three multi-function 16-bit timer/counters with PWM, full duplex USART, MICROWIRE/PLUS™, two analog comparators, two power saving HALT/IDLE modes, MIWU, idle timer, on-chip R/C oscillator, high current outputs, user selectable options (WATCHDOG™, 4 clock/oscillator modes, power-on-reset), 2.7V to 5.5V operation, program code security, and 28/40/44 pin packages.

Key Features

Low Cost 8-Bit Microcontroller
Quiet Design (Low Radiated Emissions)
Multi-Input Wakeup Pins with Optional Interrupts
Mask Selectable Clock Options (Crystal Oscillator, Crystal Oscillator Option with On-Chip Bias Resistor, External Oscillator, Internal R/C Oscillator)
Internal Power-On-Reset—User Selectable
WATCHDOG and Clock Monitor Logic—User Selectable
Eight High Current Outputs
256 or 512 Bytes On-Board RAM
8k to 32k ROM or OTP EPROM with Security Feature
Software Selectable I/O Options (TRI-STATE Output, Push-Pull Output, Weak Pull-Up Input, and High Impedance Input)
Schmitt Trigger Inputs on Ports G and L
Eight High Current Outputs
Versatile Easy to Use Instruction Set
0.67μs Instruction Cycle Time
Fourteen Multi-Source Vectored Interrupts
Fully Static CMOS Design
Low Current Drain (typically <4 μA)
Two Power Saving Modes: HALT and IDLE
Multi-Input WakeUp
Software Trap
USART (2; 1 Receive and 1 Transmit)
8-Bit Stack Pointer (Stack in RAM)
Two 8-Bit Register Indirect Data Memory Pointers
True Bit Manipulation
BCD Arithmetic Instructions
Peripheral Features: Multi-Input Wakeup Logic, Three 16-bit timers (T1—T3) with Processor Independent PWM mode, External Event Counter mode, Input Capture mode, Idle Timer (T0), MICROWIRE/PLUSSerial Interface (SPI Compatible), Full Duplex USART, Two Analog Comparators
