PT5024J [Texas Instruments]

Name: PT5024J
Brand: Texas Instruments
SKU: PT5024J
Availability: InStock

Part No:

PT5024J

Category:

Power Supplies

Manufacturer:

Texas Instruments

Description:

The PT5020 series of integrated switching regulators (ISRs) convert a positive input voltage, typically +5V, to a negative output voltage for a wide range of analog and datacom applications.

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Current Limit

150%

Derating Note

See Safe Operating Area curves or consult the factory for derating

Efficiency

75%

Input Voltage

4.75V ~ 7V

Input Voltage Note

For input voltage >7V, use PT78NR100 Series

Inrush Current

1.0A

Inrush Current Note

Above normal input current for the associated output load

Inrush Duration

1.0 mSec

Line Regulation

±0.5% ~ ±1%

Load Regulation

±0.5% ~ ±1%

Mechanical Shock

500 G's

No Load Operation

Operates at no load with reduced specifications

Operating Temperature

-20°C ~ +85°C

Output Current

1.0A

Output Ripple Max

±5%

Output Ripple Min

±2%

Output Voltage Tolerance Max

±3%

Output Voltage Tolerance Min

±1.5%

Package

3-pin SIP (suffix N), Horizontal 2-pin Tab (suffix A, C), SMD 2-pin Tab (suffix L, M)

Package 5pin Note

Tab pins must be soldered

Package Dimensions Note

Reference package code drawing for dimensions and PC board layout

Package Note

Previously known as package styles 100/110

Short Circuit Protection

No

Storage Temperature

-40°C ~ +125°C

Switching Frequency Max 1

1.2MHz

Switching Frequency Max 2

800kHz

Switching Frequency Min 1

0.8MHz

Switching Frequency Min 2

500kHz

Thermal Resistance

50°C/W

Transient Overshoot Max

5.0%

Transient Overshoot Min

3.0%

Transient Response Time

500 µSec

Vibration Suffix LM

20 G's

Vibration Suffix NAC

5 G's

Weight Suffix LM

6.5 grams

Weight Suffix NAC

4.5 grams

Products Detail

The PT5020 series of integrated switching regulators (ISRs) convert a positive input voltage, typically +5V, to a negative output voltage for a wide range of analog and datacom applications. These Plus to Minus ISRs incorporate a 'Buck-Boost' topology and are packaged in the 3-pin, single in-line pin (SIP) package configuration. Features include Negative Output, Input Voltage Range: +4.75 to +7 Volts, Laser-Trimmed, Small Footprint, Soft Start, and 5-Pin Mount Option (Suffixes L & M).

Key Features

Negative Output
Input Voltage Range: +4.75 to +7 Volts
Laser-Trimmed
Small Footprint
Soft Start
5-Pin Mount Option (Suffixes L & M)
Buck-Boost topology
3-pin SIP package

Application scenarios

analog and datacom applications
