PT6101G

Name: PT6101G
Brand: Rochester
SKU: PT6101G
Availability: InStock

Product FAQ

1. Is PT6101G available for RFQ?

Yes. PT6101G by Rochester is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

2. Why is there no fixed price for PT6101G?

Pricing for PT6101G can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

3. What are the key specifications of PT6101G?

PT6101G is a Rochester DC/DC Converters with Transient Response Time Max: 200µSec and Transient Response Time Min: 100µSec. Review the product details or submit an RFQ if you need confirmation before purchase.

4. How fast can I get a quote for PT6101G?

Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

5. How soon can PT6101G be shipped?

If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

6. Can you suggest alternatives to PT6101G?

Yes. If PT6101G is unavailable, obsolete, or does not meet your required lead time, we can help check similar Rochester DC/DC Converters parts or compatible alternatives.

Part No:

DC/DC Converters

Manufacturer:

Rochester

Description:

The PT6100 Series is a line of High-Performance 1 Amp, 12-Pin SIP (Single In-line Package) Integrated Switching Regulators (ISRs) designed to meet the on-board power conversion needs of battery powered or other equipment requiring high efficiency and small size.

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Line Regulation

±0.5%

Load Regulation

±0.5%

Mechanical Shock

500G

Mechanical Vibration

10G

Operating Temperature

-40°C ~ +85°C

Output Capacitor

100µF electrolytic or tantalum

Output Current

1.0A

Output Voltage Tolerance

±2.0%

PT6101 Efficiency

89%

PT6101 Input Voltage Max

30/38V

PT6101 Input Voltage Min

Products Detail

The PT6100 Series is a family of 1 Amp Integrated Switching Regulators (ISRs) with 90% typical efficiency, adjustable output voltage, open-collector on/off control, and low quiescent current in shutdown mode (<100µA). Features include internal short circuit protection, over-temperature protection, and a small SIP footprint. Meets FCC Part 15 Class B radiated emissions requirements. Designed for battery powered or other equipment requiring high efficiency and small size.

Key Features

90% Efficiency, Adjustable Output Voltage, Internal Short Circuit Protection, Over-Temperature Protection, On/Off Control (Ground Off), Small SIP Footprint, Meets FCC Part 15 Class B for Radiated Emissions, Wide Input Range, Low quiescent current in shutdown (<100µA)
