    PT6323R [Rochester]

    PT6323R
    PT6323R

    Part No:

    PT6323R

    Category:

    DC/DC Converters

    Manufacturer:

    Rochester

    Description:

    3 AMP ADJUSTABLE LOW VOLTAGE INPUT INTEGRATED SWITCHING REGULATORS, PT6320 series is a low voltage input (typically 7V) version of Power Trends’ high-performance 3A, 12 pin SIP Integrated Switching Regulators.

    Datasheet:

    Product FAQ

    1. Is PT6323R available for RFQ?

    Yes. PT6323R by Rochester is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

    2. Why is there no fixed price for PT6323R?

    Pricing for PT6323R can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

    3. What are the key specifications of PT6323R?

    PT6323R is a Rochester DC/DC Converters with Absolute Max Operating Temperature Max: +85°C and Absolute Max Operating Temperature Min: -40°C. Review the product details or submit an RFQ if you need confirmation before purchase.

    4. How fast can I get a quote for PT6323R?

    Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

    5. How soon can PT6323R be shipped?

    If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

    6. Can you suggest alternatives to PT6323R?

    Yes. If PT6323R is unavailable, obsolete, or does not meet your required lead time, we can help check similar Rochester DC/DC Converters parts or compatible alternatives.

    RFQ

    Part Number:

    PT6323R

    Manufacturer:

    Rochester

    Looking for Pricing? Contact us for volume pricing.

    IMPORTANT NOTICE

    Quotations are subject to stock availability and may vary with market conditions. Prices and lead times are not guaranteed until a purchase order is confirmed. Ensure your contact details are correct to avoid delays in response.

    Featured Product

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    Type
    Parameter
    Absolute Max Operating Temperature Max
    +85°C
    Absolute Max Operating Temperature Min
    -40°C
    Line Regulation
    ±0.5%
    Load Regulation
    ±0.5%
    Mechanical Shock
    500 G's
    Mechanical Vibration
    10 G's
    Output Capacitor Required
    100µF electrolytic or tantalum
    Output Current
    0.1A ~ 3.0A
    Output Voltage Tolerance Max
    ±2.0%
    Output Voltage Tolerance Typ
    ±1.0%
    PT6322 Adjustment Max
    11.25V
    PT6322 Adjustment Min
    1.88V
    PT6322 Efficiency Typ
    89% (Vin=9V, Io=0.5A, Vo=5V)
    PT6322 Input Voltage Max
    30/38V
    PT6322 Input Voltage Min
    7V
    PT6323 Adjustment Max
    6.07V
    PT6323 Adjustment Min
    1.89V
    PT6323 Efficiency Typ
    84% (Vin=9V, Io=0.5A, Vo=3.3V)
    PT6323 Input Voltage Max
    26V
    PT6323 Input Voltage Min
    7V
    Package
    12 pin SIP
    Quiescent Current
    10mA
    Recommended Operating Temperature Max
    +80°C
    Recommended Operating Temperature Min
    -40°C
    Ripple Noise Typ
    ±2%
    Short Circuit Current
    5.0 Apk
    Shutdown Current
    100µA
    Storage Temperature
    -40°C ~ +125°C
    Switching Frequency
    400kHz ~ 600kHz
    Thermal Resistance
    30°C/W
    Transient Response Max
    200 µs
    Transient Response Overshoot
    5.0%
    Transient Response Typ
    100 µs
    Weight
    6.5 grams

    Products Detail

    The PT6320 series is a low voltage input (typically 7V) version of Power Trends’ high-performance 3A, 12 pin SIP Integrated Switching Regulators. Designed with premium low threshold FETs for applications requiring very low input/output voltage differentials such as battery powered equipment. Features include 90% typical efficiency, adjustable output voltage, internal short circuit protection, over-temperature protection, and on/off control (ground off). Quiescent current in shutdown mode is less than 100µA.

    Key Features

    • Low voltage input (7V) regulators, 90% efficiency, adjustable output voltage, internal short circuit protection, over-temperature protection, on/off control (ground off), low quiescent current (<100µA in shutdown mode)

    Application scenarios

    • Battery powered equipment
    • power management

    Documents

    Datasheets:

    PT6320 SeriesPT6323R-Texas-Instruments-datasheet-10255411.pdf
