    PT6984C [Texas Instruments]

    PT6984C
    PT6984C

    Part No:

    PT6984C

    Category:

    Power Supplies

    Manufacturer:

    Texas Instruments

    RoHS Status:

    Datasheet:

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    Type
    Parameter
    Mount
    Surface Mount
    Mounting Type
    Surface Mount
    Package / Case
    23-SMD Module
    Operating Temperature
    -40°C~85°C
    Packaging
    Tray
    Series
    Excalibur™ PT6980
    Size / Dimension
    2.58Lx1.19W x 0.43 H 65.5mmx30.2mmx10.9mm
    Feature
    Remote On/Off, SCP
    Pbfree Code
    no
    Part Status
    Obsolete
    Moisture Sensitivity Level (MSL)
    3 (168 Hours)
    Number of Terminations
    23
    ECCN Code
    EAR99
    Type
    Non-Isolated PoL Module
    Applications
    ITE (Commercial)
    Max Power Dissipation
    30W
    Technology
    HYBRID
    Terminal Position
    SINGLE
    Terminal Form
    GULL WING
    Peak Reflow Temperature (Cel)
    NOT SPECIFIED
    Number of Functions
    1
    Time@Peak Reflow Temperature-Max (s)
    NOT SPECIFIED
    Base Part Number
    PT6984
    Pin Count
    23
    Number of Outputs
    2
    Qualification Status
    Not Qualified
    Efficiency
    78%
    Voltage - Input (Max)
    13.2V
    Output Voltage
    3.3V
    Max Output Current
    1.6A
    Voltage - Input (Min)
    10.8V
    Input Voltage-Nom
    12V
    Current - Output (Max)
    8.6A 1.6A
    Voltage - Output 2
    1.2V
    Control Mode
    VOLTAGE-MODE
    Current - Output 1
    10A
    Nominal Input Voltage
    12V
    Switcher Configuration
    SINGLE
    Switching Frequency-Max
    600kHz
    Height
    10.922mm
    RoHS Status
    RoHS Compliant
    Lead Free
    Lead Free

    Documents

    Datasheets:

    PT6984C-Texas-Instruments-datasheet-12810.pdfPT6984C-Texas-Instruments-datasheet-14175807.pdf
    Product FAQ

    1. Is PT6984C available for RFQ?

    Yes. PT6984C by Texas Instruments is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

    2. Why is there no fixed price for PT6984C?

    Pricing for PT6984C can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

    3. What are the key specifications of PT6984C?

    PT6984C is a Texas Instruments Power Supplies with Packaging: Tray and Time@Peak Reflow Temperature-Max (s): NOT SPECIFIED and Moisture Sensitivity Level (MSL): 3 (168 Hours). Review the product details or submit an RFQ if you need confirmation before purchase.

    4. How fast can I get a quote for PT6984C?

    Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

    5. How soon can PT6984C be shipped?

    If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

    6. Can you suggest alternatives to PT6984C?

    Yes. If PT6984C is unavailable, obsolete, or does not meet your required lead time, we can help check similar Texas Instruments Power Supplies parts or compatible alternatives.
