    5. PT78ST107V Texas Instruments

    PT78ST107V [Texas Instruments]

    PT78ST107V
    PT78ST107V

    Part No:

    PT78ST107V

    Category:

    Power Supplies

    Manufacturer:

    Texas Instruments

    Description:

    The PT78ST100 is a series of wide input range, 3-terminal regulators. These ISRs have a maximum output current of 1.5 Amps and an output voltage that is laser trimmed to a variety of industry standard voltages.

    Datasheet:

    Product FAQ

    1. Is PT78ST107V available for RFQ?

    Yes. PT78ST107V by Texas Instruments is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

    2. Why is there no fixed price for PT78ST107V?

    Pricing for PT78ST107V can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

    3. What are the key specifications of PT78ST107V?

    PT78ST107V is a Texas Instruments Power Supplies with Recommended Operating Temperature Max: +80°C and Recommended Operating Temperature Min: -40°C. Review the product details or submit an RFQ if you need confirmation before purchase.

    4. How fast can I get a quote for PT78ST107V?

    Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

    5. How soon can PT78ST107V be shipped?

    If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

    6. Can you suggest alternatives to PT78ST107V?

    Yes. If PT78ST107V is unavailable, obsolete, or does not meet your required lead time, we can help check similar Texas Instruments Power Supplies parts or compatible alternatives.

    RFQ

    Part Number:

    PT78ST107V

    Manufacturer:

    Texas Instruments

    Looking for Pricing? Contact us for volume pricing.

    IMPORTANT NOTICE

    Quotations are subject to stock availability and may vary with market conditions. Prices and lead times are not guaranteed until a purchase order is confirmed. Ensure your contact details are correct to avoid delays in response.

    Featured Product

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    Type
    Parameter
    Efficiency
    85%
    Input Voltage
    9V ~ 38V
    Operating Temperature
    -40°C ~ +85°C
    Storage Temperature
    -40°C ~ +125°C
    Weight
    6.5 grams
    Line Regulation
    ±0.2% ~ ±0.4%
    Load Regulation
    ±0.1% ~ ±0.2%
    Mechanical Shock
    500 G's
    Mechanical Vibration
    5 G's
    Output Capacitor Required
    100µF
    Output Current
    0.1A ~ 1.5A
    Output Voltage Tolerance Max
    ±2.0%
    Output Voltage Tolerance Min
    ±1.0%
    Recommended Operating Temperature Max
    +80°C
    Recommended Operating Temperature Min
    -40°C
    Ripple Noise
    65 mVpp
    Short Circuit Current
    3.5A
    Switching Frequency
    600kHz ~ 700kHz
    Thermal Resistance
    45°C/W
    Transient Response Overshoot
    5%
    Transient Response Time
    100 µs

    Products Detail

    The PT78ST100 Series is a 1.5 Amp positive step-down integrated switching regulator with high efficiency (>85%), self-contained inductor, internal short-circuit protection, over-temperature protection, and fast transient response. It features a wide input range and very small footprint. The series is very flexible and may be used in a wide variety of applications.

    Key Features

    • Very Small Footprint, High Efficiency > 85%, Self-Contained Inductor, Internal Short-Circuit Protection, Over-Temperature Protection, Fast Transient Response, Wide Input Range

    Documents

    Datasheets:

    PT78ST100 SeriesPT78ST107V-Texas-Instruments-datasheet-12233.pdf
