TMS34010FNL-40                                    Description

The TMS34010 Graphics System Processor (GSP) is an advanced high-performance CMOS 32-bitmicroprocessor optimized for graphics display systems. With a built-in instruction cache, the ability to5imultaneously access memory and registers, and an instruction set designed specifically for raster graphicsoperation, the TMS34010 provides user-programmable control of the CRT interface as well as the memoryinterface (both standard DRAM and multiport video RAM). The 1-gigabit address space is compietely bitaddressable on bit boundaries using variable width data fields (1 to 32 bits). Additional graphics addressingmodes support 1. 2,4, 8, and 16-bit wide pixels. The TMS34010 is exceptionally well-supported by graphicssoftware interface standards such as TIGA, MS-Windows, the X Window System,DGlS, and CGl, as welas a full line of hardware and software support tools. Current support is highlighted in the TMS34010Third Party Reference Guide (literaturenumber SPVBO66C)

TMS34010FNL-40                                    Features

Fully Programmable 32-Bit General-Purpose Processor with 128-Megabyte Address Range

Pixel Processing，XY Addressing.and Window Checking Built into the instruction Set

Programmable 1.2.4，8.0r 16-Bit PixelSize with 16 Boolean and 6 Arithmetic pixe Processing Options (Raster-Opsl

30 General-Purpose 32bit Registers and32-bi1 Stack Pointer

256-Byte LRU On-Chip Instruction Cache

Direct Interfacing to Both Conventional DRAM and Multiport Video RAM

Dedicated 8/16-Bit Host Processor Interface and HOLD/HLDA Interface

Programmable CRT Control(HSYNCVSYNC，BLANK)

High·Level Language Support

Ful Line of Hardware and Software Development Tools Including a Compiler

68-Leaded Packaging (PLCC)

5-Volt CMOS Technology

TMS34010FNL-40                                    Applications:

Domestic and industrial drives:

Compressors

Pumps

Fans
