TPS23785BPWP [Texas Instruments]

TPS23785BPWP Overview

PoE controller is part of the Tube package, which is included in the download.There is a way in which it is packaged which is referred to as 24-TSSOP (0.173, 4.40mm Width) Exposed Pad.As far as this application is concerned, it is a Controller (PD), DC/DC type PoE controller that is being used.There is an increase in the number of channels strong/weak as follows: 1.As a precaution, the operating temperature of this Po E controller is kept at -40°C~125°C in order to maintain its reliability.In order to operate this electrical Po E controller, it requires a voltage of 0V~57V as a supply voltage.Using the base part number of a part TPS23785, it is possible to determine its Po E controllers.Termination with a 24 termination involves terminating a transmission line with a power over ethernet controller of matching impedance.This electrical ethernet over power controller has a maximum power of 30W Watts, which is the maximum power it can deliver.In order to make it work, it has 24 pins on it.There is a peak reflow temperature of this electric ethernet power controller (Cel) of 260 degrees Celsius.In order for 960?A to perform its proper functions, it needs to have a current supply that is adequate.This electrical PoE power over ethernet controller has a maximal switching frequency of 278kHz, and that is its maximum switching frequency.A maximum input voltage of 57V can be applied to this electrical power over ethernet PoE controller.Resistance of this PoE controller is 750mOhm (*), which is the value of the resistance.

TPS23785BPWP Features

Tube package
24 pins
750mOhm (?)

TPS23785BPWP Applications

There are a lot of Texas Instruments
TPS23785BPWP Power Over Ethernet (PoE) Controllers applications.

• Wireless Access Points
• Security Cameras
• Power over Ethernet
• PoE powered device appliances
• High power (>12.95 W) powered devices
• IEEE 802.3bt (Draft) Compliant Devices
• Lighting
• Power Modules
• Dual Signature PD/Forced UPOE
• 4PPOE
