    114BPCX [Unknown]

    114BPCX
    114BPCX

    Part No:

    114BPCX

    Category:

    Audio & Video Connectors

    Manufacturer:

    Unknown

    RoHS Status:

    Product FAQ

    1. Is 114BPCX available for RFQ?

    Yes. 114BPCX by Unknown is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

    2. Why is there no fixed price for 114BPCX?

    Pricing for 114BPCX can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

    3. What are the key specifications of 114BPCX?

    114BPCX is a Unknown Audio & Video Connectors with Packaging: Bulk and Industry Recognized Mating Diameter: 6.35mm (0.250, 1/4) - Headphone and Moisture Sensitivity Level (MSL): Not Applicable. Review the product details or submit an RFQ if you need confirmation before purchase.

    4. How fast can I get a quote for 114BPCX?

    Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

    5. How soon can 114BPCX be shipped?

    If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

    6. Can you suggest alternatives to 114BPCX?

    Yes. If 114BPCX is unavailable, obsolete, or does not meet your required lead time, we can help check similar Unknown Audio & Video Connectors parts or compatible alternatives.

    RFQ

    Part Number:

    114BPCX

    Manufacturer:

    Unknown

    Looking for Pricing? Contact us for volume pricing.

    IMPORTANT NOTICE

    Quotations are subject to stock availability and may vary with market conditions. Prices and lead times are not guaranteed until a purchase order is confirmed. Ensure your contact details are correct to avoid delays in response.

    Featured Product

    Datasheet:

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    Type
    Parameter
    Factory Lead Time
    8 Weeks
    Contact Plating
    Nickel, Tin
    Mount
    Chassis Mount, PCB, Through Hole
    Mounting Type
    Panel Mount, Through Hole
    Housing Material
    Polyester, Glass Filled
    Body Material
    Brass
    Contact Material - Plating
    Tin
    Operating Temperature
    -20°C~65°C
    Packaging
    Bulk
    Series
    Hi-D® 11*
    Published
    2004
    Feature
    Mounting Hardware, Thread Lock
    Part Status
    Active
    Moisture Sensitivity Level (MSL)
    Not Applicable
    Number of Terminations
    5
    Termination
    Solder
    ECCN Code
    EAR99
    Connector Type
    Phone Jack
    Number of Positions
    3
    Color
    Black
    Gender
    Female
    Voltage - Rated
    48VDC
    Contact Finish - Mating
    TIN
    MIL Conformance
    NO
    DIN Conformance
    NO
    IEC Conformance
    NO
    Option
    GENERAL PURPOSE
    Orientation
    Straight
    Shielding
    Unshielded
    Depth
    15.74mm
    Current Rating
    3A
    Number of Ports
    1
    Number of Poles
    5
    Thread Size
    3/8-32
    Number of Positions/Contacts
    3 Conductors, 5 Contacts
    Includes
    3 pcs - 1 Connector, 1 Nut, 1 Washer
    Internal Switch(s)
    Two Switches
    Body Color
    Silver, Black
    Panel Hole Size
    0.375 9.52mm
    Industry Recognized Mating Diameter
    6.35mm (0.250, 1/4) - Headphone
    Actual Diameter
    0.250 (6.35mm)
    Signal Lines
    Stereo (3 Conductor, TRS)
    Length
    15.74mm
    Width
    15.7mm
    REACH SVHC
    No SVHC
    RoHS Status
    RoHS Compliant

    Documents

    Datasheets:

    114BPCX-Switchcraft-datasheet-24496.pdf114BPCX-Switchcraft-datasheet-517174.pdf114BPCX-Switchcraft-datasheet-62310036.pdf114BPCX-Switchcraft-datasheet-11003202.pdf114BPCX-Switchcraft-datasheet-11807446.pdf
