2N4916 [Unknown]

2N4916 Overview

DC current gain' is equal to the ratio of the collector current to the base current, something like Ic/Ib, and this device has 70 @ 10mA 1V DC current gain.VCE saturation indicates Ic is at maximum level (saturated), whereas vce saturation (Max) indicates there is no saturation.There is a transition frequency of 400MHz in the part.Single BJT transistor shows a 30V maximal voltage - Collector EmSingle BJT transistorter Breakdown.

2N4916 Features

the DC current gain for this device is 70 @ 10mA 1V
the vce saturation(Max) is 300mV @ 5mA, 50mA
a transition frequency of 400MHz

2N4916 Applications

There are a lot of Central Semiconductor Corp
2N4916 applications of single BJT transistors.

• Inverter
• Interface
• Driver
• Muting
