ALD1701BPAL Overview

In the package, you will find a 8-DIP (0.300, 7.62mm)-case to contain the op amp ic. The instrumentation amplifier in this picture is of the General Purpose-type. A Tube case is used for delivering the op amp. The op amp ic has an array of 8 pins on it. Op amp rates 2mV as input offset voltage. For this electrical component, Through Hole is the recommended mounting type. According to the manufacturer, this buffer op amp works well at 0°C~70°C , which is a good operating temperature. Using an 120?A supply current, this operational amplifier ics can be operated. You should keep the voltage gain at 107.96dB for the time being. A instrumentation amplifier like this has 1 circuits. On the buffer amps, there are 1 channels that can be used. Buffer amplifier produces Rail-to-Rail signals, which is one of its many benefits. To operate this buffer amplifier, the temperature must not be lower than 0°C. A temperature greater than 70°C should not be used for the operation of buffer amplifier. The operating supply voltage of the buffer op amp is rated at 5V. There is a recommendation that this electrical part be used with a supply with 120?A current rating. This electrical part should be conducted under the dual supply voltage of 6V volts when you conduct this part.

ALD1701BPAL Features

107.96dB voltage gain
Output Type: Rail-to-Rail

ALD1701BPAL Applications

There are a lot of Advanced Linear Devices Inc.
ALD1701BPAL Instrumentational OP Amps applications.

• Multiplication circuits
• Division circuits
• Precision measurement
• Power control
• Information processing
• Weak signal detection
• Signal amplification
• Signal filtering
• Signal operation
• Video computer boards
