Name: CHB100W-48S28
Brand: Unknown
SKU: CHB100W-48S28

Type

Parameter

Factory Lead Time

8 Weeks

Mounting Type

Through Hole

Package / Case

Half Brick

Operating Temperature

-40°C~100°C With Derating

Series

CHB100W (100W)

Size / Dimension

2.40Lx2.28W x 0.50 H 61.0mmx57.9mmx12.7mm

Feature

Remote On/Off, OCP, OTP, OVP, SCP, UVLO

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Type

Isolated Module

Applications

ITE (Commercial)

Power (Watts)

100W

Number of Outputs

Efficiency

86%

Voltage - Isolation

1.5kV

Voltage - Input (Max)

75V

Voltage - Output 1

28V

Voltage - Input (Min)

18V

Current - Output (Max)

3.57A

Control Features

Enable, Active High

RoHS Status

RoHS Compliant

Description: The Cincon CHB100W-48S28 is an isolated DC/DC converter that provides up to 100W of power. It has a wide input voltage range of 18-36V and a single output voltage of 48V. It is designed to be highly efficient, with a typical efficiency of up to 94%. It also features a wide operating temperature range of -40°C to +85°C.

Features:
• Wide input voltage range of 18-36V
• Single output voltage of 48V
• High efficiency of up to 94%
• Wide operating temperature range of -40°C to +85°C
• Over-voltage, over-current, and short-circuit protection
• RoHS compliant

Applications: The Cincon CHB100W-48S28 is suitable for a variety of applications, including industrial automation, telecommunications, and medical equipment. It is also suitable for use in harsh environments, such as in outdoor or extreme temperature applications.
