    Part number
    Part number
    1. Home/
    2. All Categories/
    3. Connectors/
    4. Audio & Video Connectors/
    5. MDSMT4BRATRX Unknown

    MDSMT4BRATRX [Unknown]

    MDSMT4BRATRX
    MDSMT4BRATRX

    Part No:

    MDSMT4BRATRX

    Category:

    Audio & Video Connectors

    Manufacturer:

    Unknown

    RoHS Status:

    Product FAQ

    1. Is MDSMT4BRATRX available for RFQ?

    Yes. MDSMT4BRATRX by Unknown is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

    2. Why is there no fixed price for MDSMT4BRATRX?

    Pricing for MDSMT4BRATRX can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

    3. What are the key specifications of MDSMT4BRATRX?

    MDSMT4BRATRX is a Unknown Audio & Video Connectors with Packaging: Bulk and Industry Recognized Mating Diameter: 2.50mm (0.094, 3/32, Sub Mini, Miniature) - Headphone and Number of Positions/Contacts: 3 Conductors, 5 Contacts. Review the product details or submit an RFQ if you need confirmation before purchase.

    4. How fast can I get a quote for MDSMT4BRATRX?

    Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

    5. How soon can MDSMT4BRATRX be shipped?

    If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

    6. Can you suggest alternatives to MDSMT4BRATRX?

    Yes. If MDSMT4BRATRX is unavailable, obsolete, or does not meet your required lead time, we can help check similar Unknown Audio & Video Connectors parts or compatible alternatives.

    RFQ

    Part Number:

    MDSMT4BRATRX

    Manufacturer:

    Unknown

    Looking for Pricing? Contact us for volume pricing.

    IMPORTANT NOTICE

    Quotations are subject to stock availability and may vary with market conditions. Prices and lead times are not guaranteed until a purchase order is confirmed. Ensure your contact details are correct to avoid delays in response.

    Featured Product

    Datasheet:

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    Type
    Parameter
    Factory Lead Time
    12 Weeks
    Contact Material
    Copper Alloy
    Mount
    Surface Mount
    Mounting Type
    Surface Mount, Right Angle
    Housing Material
    Thermoplastic
    Contact Material - Plating
    Silver
    Operating Temperature
    -25°C~85°C
    Packaging
    Bulk
    Series
    MDSMT
    Published
    2001
    JESD-609 Code
    e4
    Feature
    Board Guide
    Part Status
    Active
    Number of Terminations
    5
    Termination
    Solder
    Connector Type
    Phone Jack
    Gender
    Female
    Voltage - Rated
    250V
    Contact Finish - Mating
    NOT SPECIFIED
    MIL Conformance
    NO
    DIN Conformance
    NO
    IEC Conformance
    NO
    Option
    GENERAL PURPOSE
    Orientation
    Right Angle
    Shielding
    Unshielded
    Depth
    12mm
    Current Rating
    3A
    Housing Color
    Black
    Max Current Rating
    3A
    Number of Ports
    1
    Number of Poles
    3
    Number of Positions/Contacts
    3 Conductors, 5 Contacts
    Internal Switch(s)
    Two Switches
    Industry Recognized Mating Diameter
    2.50mm (0.094, 3/32, Sub Mini, Miniature) - Headphone
    Actual Diameter
    0.102 (2.60mm)
    Signal Lines
    Stereo (3 Conductor, TRS)
    Length
    9mm
    RoHS Status
    RoHS Compliant
    Lead Free
    Lead Free

    Documents

    Datasheets:

    MDSMT4BRATRX-Switchcraft-datasheet-77796.pdfMDSMT4BRATRX-Switchcraft-datasheet-12387988.pdf
