PA90EE [Unknown]

PA90EE Overview

A 12-SIP case is used to package the op amp. Power-type instrumentation amplifiers are used in this application. The case in which buffer amplifier is delivered is called a Tube case. It is estimated that there will be 12 terminations in the next few months. There are a total of 12 pins on this op amp. It is important to remember that this op amp should be operated at a voltage of 150V volts. It should be noted that this op amp is a type of Operational Amplifier device. In terms of the input offset voltage, instrumentation amplifier rates at 500μV. It is recommended that this electronic component be mounted using the Through Hole mounting type. In terms of operating temperature, this instrumentation amplifier performs well at a temperature of about -25°C~85°C . An 10mA volt supply current is needed for this linear amplifier to operate. On this instrumentation amplifier, there are 1 circuits that are connected together. The Apex Precision Power® indicates the series number of the op amp.

PA90EE Features

12 Pins
supply voltage of 150V

PA90EE Applications

There are a lot of Apex Microtechnology
PA90EE Instrumentational OP Amps applications.

• Addition operation circuits
• Subtraction operation circuits
• single/dual op amp sum and difference circuits
• Integrator circuits
• Differentiator circuits
• Logarithmic operation circuits
• Exponential operation circuits
• Multiplication circuits
• Division circuits
• Precision measurement
