CA10N Description

The CA10N is a high-performance, precision-regulated, high-voltage converter with high stability and low ripple, along with a built-in voltage monitor output and an onboard precision voltage reference. Each model is programmed from 0 to 100% of rated output via a DAC-compatible high-impedance programming input. The voltage reference can be used to drive the high voltage output at 100% or to adjust the output with an external potentiometer or voltage divider. The output voltage monitor is internally buffered to provide a low impedance (up to 1 mA) signal to external circuitry. A quasi-sinewave oscillator, internal transformer shielding, and an isolated steel case reduce EMI/RFI radiation to extremely low levels.

CA10N Features

5V and 12V Input Models

Precision Voltage Regulated

Output Voltages from 100V to 2000V

0 to 100% Programmable Output

On-board Voltage Reference

Operating Temperature -10°C to +50°C

<25ppm/°C Temperature Coefficient

Shielded Case with Isolated Case Ground

Ultra Low Ripple, down to 5ppm

3 Year Warranty

CA10N Applications

Automotive

Advanced driver assistance systems (ADAS)

Enterprise systems

Enterprise machine

Personal electronics

Home theater & entertainment
