The ACEPACK DRIVE is a compact sixpack module optimized for hybrid and electric vehicles traction inverter. This power module features switches based on silicon carbide Power MOSFET 3^rd generation, are characterized by very low R_DS(on), very limited switching losses and outstanding performances in synchronous rectification working mode. This will ensure superb efficiency in final application, saving battery recharging cycles.

A copper base plate with pin-fin base structure make direct fluid cooling available for this power module minimizing thermal resistance.

A dedicated pin-out has been developed to get the best switching performance and press-fit pins will ensure optimal connection with driving board.

• AQG 324 qualified
• 1200 V blocking voltage
• 2.55 mΩ of typical R_DS(on)
• Maximum operating junction temperature T_J = 175 °C
• Very low switching energy
• Low inductive compact design for an higher power density
• Si₃N₄ AMB substrate to improve thermal performance
• SiC Power MOSFET chip sintered to substrate for improved lifetime
• 4.2 kV DC 1 s isolation
• Directly liquid cooled base plate with pin-fins
• Three integrated NTC temperature sensors
• Long AC bus bar compatible with phase current sensing
