The STM32MP135 Discovery kit (STM32MP135F-DK) leverages the capabilities of the 1 GHz STM32MP135 microprocessors to allow users to develop easily applications using STM32 MPU OpenSTLinux Distribution software.

It includes an ST-LINK embedded debug tool, LEDs, push-buttons, two 10/100 Mbit/s Ethernet (RMII) connectors, one USB Type-C^® connector, four USB Host Type-A connectors, and one microSD™ connector.

To expand the functionality of the STM32MP135 Discovery kit, one GPIO expansion connector is also available for third-party shields.

Additionally, the STM32MP135 Discovery kit features an LCD display with a touch panel, Wi‑Fi^® and Bluetooth^® Low Energy capability, and a 2-megapixel CMOS camera module.

It also provides secure boot and cryptography features.

• STM32MP135FAF7 MPU with an Arm^® Cortex^®‑A7 32-bit processor at 1 GHz, in a TFBGA320 package
• ST PMIC STPMIC1
• 4-Gbit DDR3L, 16 bits, 533 MHz
• 4.3 480×272 pixels LCD display module with capacitive touch panel and RGB interface
• UXGA 2-megapixel CMOS camera module (included) with MIPI CSI-2^® / SMIA CCP2 deserializer
• Wi‑Fi^® 802.11b/g/n
• Bluetooth^® Low Energy 4.1
• Dual 10/100 Mbit/s Ethernet (RMII) compliant with IEEE-802.3u, one with Wake on LAN (WoL) support
• USB Host 4-port hub
• USB Type-C^® DRP based on an STM32G0 device
• 4 user LEDs
• 4 push-buttons (2× user, tamper, and reset)
• 1 wake-up button
• Board connectors:
  • Dual-lane MIPI CSI-2^® camera module expansion
  • 2× Ethernet RJ45
  • 4× USB Type-A
  • USB Micro-B
  • USB Type-C^®
  • microSD™ card holder
  • GPIO expansion
  • 5 V / 3 A USB Type-C^® power supply input (charger not provided)
  • VBAT for power backup
• On-board current measurement
• On-board STLINK-V3E debugger/programmer with USB re-enumeration capability: mass storage, Virtual COM port, and debug port
• Full mainline open-source Linux^® STM32 MPU OpenSTLinux Distribution (such as STM32MP1Starter) software and examples
• Support of several Integrated Development Environments (IDEs) including STM32CubeIDE
• Bare metal support for RTOS (Microsoft^® Azure^®)
