The STNRG011A embodies a multi-mode (transition-mode and DCM) PFC controller, a high- voltage double-ended controller for the LLC resonant half-bridge, an 800 V-rated startup generator and a sophisticated digital engine, that manage optimal operation of three blocks.

The STNRG011A manages only input line AC.

The device comes in a 20-pin SO package and offers an advanced solution for power- factor-corrected high-efficiency converters supposed to comply with the most stringent energy saving regulations.

The power system and the control algorithms are managed by an 8-bit core with dedicated fast peripherals (SMED). Optimized digital algorithms together with HW analog IPs are implemented to guarantee a very high performance, BOM optimization and robustness.

The digital algorithms are stored into an internal ROM memory and all key application parameters can be stored into a device's NVM (non-volatile memory) memory during the production phase allowing wide configurability and calibration.

The device can also externally communicate through a 2-pin UART, allowing the monitoring function, the black box storing into an external E2PROM and the software patch upload from the external E2PROM.

• Digital combo multi-mode PFC + time-shift LLC resonant half-bridge controller
• Onboard 800 V startup circuit, line sense and X-cap discharge compliant with IEC 62368-1, for reduced standby power
• Enhanced fixed on time multi-mode TM PFC controller with input voltage feed-forward, THD optimizer and frequency limitation
• Complete set of PFC protections
• Time-shift control of resonant half-bridge
• Enhanced burst-mode at light load with fast transient response and line adaptive half- bridge brown-out protection
• Complete set of half-bridge protections
• Available in SO20 package
