10120-72B2VC [3M]

Name: 10120-72B2VC
Brand: 3M
SKU: 10120-72B2VC

Part No:

10120-72B2VC

D-Sub Connectors

Manufacturer:

3M

Description:

Package:

-

RoHS Status:

Datasheet:

Production Status:

In Stock Status:

Specification

Type

Parameter

Contact Plating

Gold

Mount

Panel, Through Hole

Mounting Type

Panel Mount, Through Hole, Right Angle

Housing Material

Plastic

Series

101, Mini D Ribbon (MDR)

Published

2003

Feature

Board Lock, Shielded

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Termination

Solder

Connector Type

Plug

Type

Board to Board

Number of Positions

Number of Rows

Gender

Male

Contact Finish

Gold

Housing Color

Black

Flange Feature

Housing/Shell (M2.6)

Connector Style

Center Strip Contacts

Height

9.7mm

Length

33.3mm

Width

16.5mm

RoHS Status

RoHS Compliant

Flammability Rating

UL94 V-0

Lead Free

Contains Lead

Products Detail

10120-72B2VC Description

D-Shaped connectors provide an electrical connection in a metal shell manufactured in the shape of a "D." Our d-connectors are compact pin and socket connectors designed to transmit power and signal in communications equipment, especially in high-density packages.

10120-72B2VC Features

Wiper-on-wiper contact for reliable repetitive

plugging

Rugged die cast metal case construction

Screw or ground lock PCB retention

Normal and reverse ?D? interface options for

board to board flexibility

IEEE 1284C Interface as a 36 contact

connector

Contacts: 20, 26, 36 and 50

10120-72B2VC Applications

? Portable, Battery-Powered Equipment

? Data Acquisition Systems

? Medical Equipment

? Hand-Held Test Equipment

Key Features

No key features available

Application scenarios

No application scenarios available
