3443-71 [3M]

Low-profile PCB connector series with 7.3 mm terminated height for space-constrained applications. Features single connector termination to reduce cost, solder bumps for board cleaning, and fits standard .100" x .100" header layout while using less board area than 4-row designs. Insulation material is Glass Filled Polyester (UL 94V-0, Gray). Contacts use Beryllium Copper with Nickel underplating and Gold Flash plating on U slots and solder tails. Accommodates 26 AWG Stranded, 28 AWG Solid/Stranded, and 30 AWG Solid wires. Electrical ratings: 1.0 A current, >1,000 MΩ insulation resistance at 500 VDC, and 1,000 V AC withstand voltage for 1 minute. Operating temperature range: -55°C to +105°C. Wave solder process only. RoHS compliant.
