BS-22-10 [3M]

Name: BS-22-10
Brand: 3M
SKU: BS-22-10
Availability: InStock

Part No:

BS-22-10

Category:

Terminals

Manufacturer:

3M

RoHS Status:

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Factory Lead Time

3 Weeks

Contact Material

Copper, ETP

Mount

Free Hanging

Mounting Type

Free Hanging (In-Line)

Weight

680.388555mg

Packaging

Bulk

Published

2006

Feature

Butted Seam

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Termination

Crimp

Color

Red

Gender

Male

Contact Finish

Tin

Wire Gauge

14-16 AWG

Wire Gauge (Max)

18 AWG

Wire Gauge (Min)

22 AWG

Insulation Diameter

0.090 (2.29mm)

Insulation

Non-Insulated

Terminal Type

Flanged

Stud/Tab Size

10 Stud

Length

16.51mm

Length - Termination

0.250 6.35mm

Length - Overall

0.650 16.50mm

Width - Outer Edges

0.300 7.62mm

Length - Ring Center to Termination

0.250 6.35mm

RoHS Status

RoHS Compliant

Documents

Datasheets:

BS-22-10-3M-datasheet-154605.pdf

ConflictMineralStatement:

3M-company-24.pdf

Product FAQ

1. Is BS-22-10 available for RFQ?

Yes. BS-22-10 by 3M is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

2. Why is there no fixed price for BS-22-10?

Pricing for BS-22-10 can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

3. What are the key specifications of BS-22-10?

BS-22-10 is a 3M Terminals with Packaging: Bulk and Length - Ring Center to Termination: 0.250 6.35mm and Moisture Sensitivity Level (MSL): 1 (Unlimited). Review the product details or submit an RFQ if you need confirmation before purchase.

4. How fast can I get a quote for BS-22-10?

Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

5. How soon can BS-22-10 be shipped?

If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

6. Can you suggest alternatives to BS-22-10?

Yes. If BS-22-10 is unavailable, obsolete, or does not meet your required lead time, we can help check similar 3M Terminals parts or compatible alternatives.
