Name: A-2014-2-2
Brand: ASSMANN WSW Components
SKU: A-2014-2-2

A-2014-2-2 [ASSMANN WSW Components]

Part No:

A-2014-2-2

Category:

Modular Connectors / Ethernet Connectors

Manufacturer:

ASSMANN WSW Components

Description:

Jack Tray Unshielded 8p8c (RJ45, Ethernet) 1 Port Vertical Solder Through Hole -40°C~85°C

Package:

-

RoHS Status:

Datasheet:

-

Production Status:

In Stock Status:

Specification

Type

Parameter

Factory Lead Time

23 Weeks

Contact Material

Phosphor Bronze

Mount

Through Hole

Mounting Type

Through Hole

Housing Material

Polyester, Glass Filled

Operating Temperature

-40°C~85°C

Packaging

Tray

Published

2014

Feature

Board Lock, Panel Stops

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Termination

Solder

Connector Type

Jack

Total Number of Contacts

8

Orientation

Vertical

Shielding

Unshielded

Terminal Pitch

2.54mm

Reference Standard

UL

Contact Finish

Gold

Reliability

COMMERCIAL

Body Length or Diameter

0.598 inch

PCB Contact Pattern

STAGGERED

Body Breadth

0.654 inch

Contact Gender

MALE

Body Depth

0.642 inch

Contact Style

TELCOM, MODULAR

Contact Resistance

30mOhm

Number of Ports

1

Durability

750 Cycles

Insulator Color

BLACK

Direction

User Selectable

Number of Positions/Contacts

8p8c (RJ45, Ethernet)

LED Color

Does Not Contain LED

Tab Direction

User Selectable

RoHS Status

RoHS Compliant

Products Detail

A-2014-2-2 Overview

The product is packaged in Jack.Through Hole is the mounting type.Packaging for the product is carried out via a Tray case.A variety of tasks can be managed via its 1 ports.With its Board Lock, Panel Stops feature, it is more powerful in many ways.In this case, Through Hole mounts the part.The device is operating at -40°C~85°C Operating Temperature.
