HEDS-8902 [Avago]

Name: HEDS-8902
Brand: Avago
SKU: HEDS-8902
Availability: InStock

Part No:

HEDS-8902

Category:

LED Lighting Mechanical

Manufacturer:

Avago

Description:

High performance, low cost, two and three channel optical incremental encoders.

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Supply Voltage

4.5V ~ 5.5V

Acceleration Max

250,000 rad/sec²

Bolt Circle 2 Screw

19.05 mm

Bolt Circle 3 Screw

20.90 mm

Bolt Circle External Ears

46.0 mm

Encoder Base Plate Thickness

0.33 mm

HEDM 5500 5600 Operating Temperature Max

70°C

HEDM 5500 5600 Operating Temperature Min

-40°C

HEDM 5500 5600 Supply Current Typ

57mA

HEDM 5540 5640 Operating Temperature Max

85°C

HEDM 5540 5640 Operating Temperature Min

-40°C

HEDM 5540 5640 Supply Current Typ

57mA

HEDS 5500 5600 Supply Current Typ

40mA

HEDS 5540 5640 Supply Current Typ

57mA

HEDS Operating Temperature Max

100°C

HEDS Operating Temperature Min

-40°C

Hub Set Screw

(2-56)

Mounting Screw Size 2 Screw

M2.5 or (2-56)

Mounting Screw Size 3 Screw

M1.6 or (0-80)

Mounting Screw Size External Ears

M2.5 or (2-56)

Output Type

TTL compatible

Resolution

up to 1024 CPR

Resolution Max

1024 CPR

Supply Current

17mA ~ 85mA

Velocity Max

30,000 RPM

Vibration

20 g, 5 to 1000Hz

Products Detail

High performance, low cost optical incremental encoders with two or three channel outputs. Features include lensed LED source, integrated detector and output circuitry, and codewheel. HEDS series uses metal codewheel, HEDM series uses film codewheel for resolutions up to 1024 CPR. Easy assembly with external mounting ears available. TTL compatible, single 5 V supply.

Key Features

Two channel quadrature output with optional index pulse
Quick and easy assembly
No signal adjustment required
External mounting ears available
Low cost
Resolutions up to 1024 counts per revolution
Small size
Operating temperature -40°C to 100°C
TTL compatible
Single 5 V supply

Application scenarios

printers
plotters
tape drives
positioning tables
automatic handlers

Documents

Datasheets:

HEDS-8902-Broadcom-datasheet-37142605.pdf HEDS-8902-Avago-datasheet-99490.pdf HEDS-8902-Avago-datasheet-10307691.pdf

Product FAQ

1. Is HEDS-8902 available for RFQ?

Yes. HEDS-8902 by Avago is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

2. Why is there no fixed price for HEDS-8902?

Pricing for HEDS-8902 can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

3. What are the key specifications of HEDS-8902?

HEDS-8902 is a Avago LED Lighting Mechanical with HEDM 5500 5600 Operating Temperature Max: 70°C and HEDM 5500 5600 Operating Temperature Min: -40°C. Review the product details or submit an RFQ if you need confirmation before purchase.

4. How fast can I get a quote for HEDS-8902?

Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

5. How soon can HEDS-8902 be shipped?

If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

6. Can you suggest alternatives to HEDS-8902?

Yes. If HEDS-8902 is unavailable, obsolete, or does not meet your required lead time, we can help check similar Avago LED Lighting Mechanical parts or compatible alternatives.
