AUIRGU4045D [Infineon]

Part No:

AUIRGU4045D

Name: AUIRGU4045D
Brand: Infineon
SKU: AUIRGU4045D

Category:Transistors

Manufacturer:Infineon

Description:

Package:-

RoHS Status:

Datasheet:

Production Status:

In Stock Status:

Specification

Type

Parameter

Factory Lead Time

13 Weeks

Mounting Type

Through Hole

Package / Case

TO-251-3 Short Leads, IPak, TO-251AA

Surface Mount

Transistor Element Material

SILICON

Operating Temperature

-55°C~175°C TJ

Packaging

Tube

Published

2011

JESD-609 Code

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

ECCN Code

EAR99

Terminal Finish

Matte Tin (Sn) - with Nickel (Ni) barrier

Terminal Position

SINGLE

Peak Reflow Temperature (Cel)

260

Reach Compliance Code

compliant

Time@Peak Reflow Temperature-Max (s)

JESD-30 Code

R-PSIP-T3

Qualification Status

Not Qualified

Number of Elements

Rise Time-Max

15ns

Configuration

SINGLE WITH BUILT-IN DIODE

Input Type

Standard

Power - Max

77W

Transistor Application

POWER CONTROL

Polarity/Channel Type

N-CHANNEL

Reverse Recovery Time

74ns

Voltage - Collector Emitter Breakdown (Max)

600V

Current - Collector (Ic) (Max)

12A

Power Dissipation-Max (Abs)

77W

Turn On Time

38 ns

Vce(on) (Max) @ Vge, Ic

2V @ 15V, 6A

Turn Off Time-Nom (toff)

127 ns

IGBT Type

Trench

Gate Charge

19.5nC

Current - Collector Pulsed (Icm)

18A

Td (on/off) @ 25°C

27ns/75ns

Gate-Emitter Voltage-Max

20V

Gate-Emitter Thr Voltage-Max

6.5V

Fall Time-Max (tf)

22ns

RoHS Status

RoHS Compliant

Products Detail

AUIRGU4045D Description

BIPOLAR TRANSISTOR WITH INSULATED GATE AND ULTRAFAST SOFT RECOVERY DIODE

AUIRGU4045D Features

?Low-voltage on-trench IGBT technology

? Minimal Switching Losses

?175 °C is the maximum junction temperature.

?SCSOA 5 ps

?Round RBSOA

?All components examined for 1 were 100%

?VCE (on) Temperature Coefficient in the positive.

?Co-pak Diode with Ultra Fast Soft Recovery

?Tighter Parameter Distribution

?RoHS and lead-free compliant

?Auto Qualification

AUIRGU4045D Applications

Switching applications

Key Features

No key features available

Application scenarios

No application scenarios available

Documents

Datasheets:

AUIRG(R,U)4045D

PCN Packaging:

Package Drawing Update 19/Aug/2015
