AUIRLZ44Z Overview

Avalanche breakdown occurs when energy is applied to the MOSFET, and the avalanche energy ratings (Eas) are 78 mJ.A device's maximal input capacitance is 1620pF @ 25V, which is defined as the capacitance between its input terminals with either input grounded.This device's continuous drain current (ID) is 51A, which represents the maximum continuous current it can conduct.In this device, the drain-source breakdown voltage is 55V and the drain-source breakdown voltage is the VDS at which a specified value of ID flows.Its turn-off delay time is 25 ns, which is the time to charge the device's input capacitance before drain current conduction begins.In terms of pulsed drain current, it has a maximum of 204A, which is its maximum rated peak drain current.Input capacitance charging takes time before drain current conduction begins, so the turn-on delay time is 14 ns.Gate-source voltage, or VGS, is the voltage across a FET transistor's gate-source terminal, and can be 16V volts.An electrical device's threshold voltage is the point at which any of its operations will become active, and this transistor has a 1V threshold voltage.This device reduces its overall power consumption by using drive voltage (4.5V 10V).

AUIRLZ44Z Features

the avalanche energy rating (Eas) is 78 mJ
a continuous drain current (ID) of 51A
a drain-to-source breakdown voltage of 55V voltage
the turn-off delay time is 25 ns
based on its rated peak drain current 204A.
a threshold voltage of 1V

AUIRLZ44Z Applications

There are a lot of Infineon Technologies
AUIRLZ44Z applications of single MOSFETs transistors.

• Consumer Appliances
• Lighting
• Uninterruptible Power Supply
• AC-DC Power Supply
• Synchronous Rectification for ATX 1 Server I Telecom PSU
• Motor drives and Uninterruptible Power Supplies
• Micro Solar Inverter
• DC/DC converters
• Power Tools
• Motor Drives and Uninterruptible Power Supples
