    XRD98L62EVAL [EXAR]

    XRD98L62EVAL
    XRD98L62EVAL

    Part No:

    XRD98L62EVAL

    Category:

    Other Modules

    Manufacturer:

    EXAR

    Description:

    The XRD98L62 is a complete, low power CCD Image Digitizer for digital motion and still cameras.

    Datasheet:

    Product FAQ

    1. Is XRD98L62EVAL available for RFQ?

    Yes. XRD98L62EVAL by EXAR is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

    2. Why is there no fixed price for XRD98L62EVAL?

    Pricing for XRD98L62EVAL can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

    3. What are the key specifications of XRD98L62EVAL?

    XRD98L62EVAL is a EXAR Other Modules with Max Junction Temperature: 150°C and Operating Temperature: -15°C ~ 70°C. Review the product details or submit an RFQ if you need confirmation before purchase.

    4. How fast can I get a quote for XRD98L62EVAL?

    Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

    5. How soon can XRD98L62EVAL be shipped?

    If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

    6. Can you suggest alternatives to XRD98L62EVAL?

    Yes. If XRD98L62EVAL is unavailable, obsolete, or does not meet your required lead time, we can help check similar EXAR Other Modules parts or compatible alternatives.

    RFQ

    Part Number:

    XRD98L62EVAL

    Manufacturer:

    EXAR

    Looking for Pricing? Contact us for volume pricing.

    IMPORTANT NOTICE

    Quotations are subject to stock availability and may vary with market conditions. Prices and lead times are not guaranteed until a purchase order is confirmed. Ensure your contact details are correct to avoid delays in response.

    Featured Product

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    Type
    Parameter
    Supply Current
    70mA
    Supply Voltage
    2.7V ~ 3.6V
    Operating Temperature
    -15°C ~ 70°C
    Package
    48-pin TQFP
    ESD Protection
    2000V
    Max Junction Temperature
    150°C
    Max Sampling Rate
    30 MSPS
    Power Dissipation
    180mW
    Standby Current
    0.5mA
    Storage Temperature
    -65°C ~ 150°C
    Thermal Resistance
    105°C/W

    Products Detail

    The XRD98L62 includes a high bandwidth differential Correlated Double Sampler (CDS), 10-bit digitally Programmable Gain Amplifier (PGA), 12-bit Analog-to-Digital Converter (ADC) and improved digitally controlled black level auto-calibration circuitry with programmable pixel averager, hot pixel clipper, and a DNS filter. It features two 8-bit serial controlled DACs for external analog signals, operates from a single 2.7V to 3.6V power supply, and is packaged in 48-pin TQFP for space and weight reduction.

    Key Features

    • 12-bit Resolution ADC
    • Two Serial Controlled 8-bit D/A Converters
    • 30MHz Sampling Rate
    • 0.5mA Stand-by Mode Current
    • 10-bit Programmable Gain: 0dB to 36dB PGA
    • Three-state Digital Outputs
    • Digitally Controlled Offset-Calibration with Pixel Averager and Hot Pixel Clipper
    • 2,000V ESD Protection
    • 48-pin TQFP Package
    • DNS Filter Removes Black Level Digital Noise
    • Widest Black Level Calibration Range at Maximum Gain
    • 1ns/step Programmable Aperture Delay on SPIX, SBLK and ADCLK
    • Manual Control of Offset DAC via Serial Port for use with High-speed Scanners
    • Single 2.7V to 3.6V Power Supply
    • Optimize Power with External Resistor to 180mW
    • View Finder Mode, 6-bit Resolution, 25% Less Power
    • Low Power for Battery Operation

    Application scenarios

    • Mega pixel Digital Still Cameras
    • Digital Camcorders
    • 3 CCD Professional/Broadcast Camera
    • Line Scan Cameras
    • PC Video Cameras
    • CCTV/Security Cameras
    • Industrial/Medical Cameras
    • 2D Bar Code Readers
    • High Speed Scanners
    • Digital Copiers

    Documents

    Datasheets:

    XRD98L62
